Specifications
8'' special car DVD player for Ford FOCUS1,support 1080P full format decoding
2,real 501 sound channel
DJ-8016 specific car GPS DVD player with CAN-BUS, TV, radio, bluetooth, 3D UI, SD, USB, AUX, etc.
Functions Features:
1,Using advanced MTK3360 platform for the development, can realize interface drag,,background wallpaper and logo changing dynamic effect, practicability and entertainment of the infinite reinforced.
2,Support external car DVR,video and playback of video can be displayed simultaneously on the screen and touch control of the DVR,so it can record you and safety of your car.
3,Support DVD/CD/MP3/MP4/JPG multiple formats disc play, super error correction disc reading, prolong the life of the pick-up.
4,SD card/USB play, Support DVD/CD/MP3/MP4/JPG/RMVB(720P) multiple formats disc play.
5,High sensitivity radio,support RDS function.Support worldwide countries receive frequency.
6,Built-in Bluetooth hands free call function, call log, and support Bluetooth music play.
7,Built-in GPS module(Windows CE 6.0) and it has the world highest sensitivity and tracking ability, under the environment of city it has the highest positioning rate and precision(optional).
8,Built-in TV receive module, you can choose digital TV or analog TV. Digital TV can custom all countries standard based on your requirements. Analog TV is full system, countries all the world can use(optional)
9,External digital TV box,AV play functions enhanced(optional)
10,Support connection to iPod(optional).
11,Support dual input of reversing camera and front camera,can connect 360 degree panoramic reflection imaging system to make sure of safety.
12,Support AUX input/ output,subwoofer output.
13,Support 29 languages
Product Description |
Using Environment |
Model No.: DJ8016 |
Working Temperature: -10degree-70degree |
Size: 200*178*100 mm |
Storage Temperature: -20degree-85degree |
Description : Car Multimedia main unit |
Humidity: 65% |
System Platform | |
|
Operation system:MTK 3360(Windows CE 6.0)
|
Built-in digital TV(optional):can choose all country’s standards. External digital TV (optional): can choose all country’s standards |
|
Flash:TOSHIBA0R2113 MCU:MN101EF51A |
Analog TV: HJ-1A-L Full system |
Bluetooth module:MT6622N | |
DVD:3360 integrated |
GPS:MT3360 |
DVD pickup head:Sanyo HOP-1200XH |
TFT backlight:MP3302 |
DVD loader:Corepine DL-C35C-C |
Main power IC:MPS1584 |
Radio:IS4755(RDS) |
Amplifer:TDA7388 |
Audio processing:PCM1606E |
|
Standard Accessories: |
||||
Type |
Details |
Description |
Remarks |
|
|
Power |
working Voltage |
DC 10V~16V |
||
working Current |
1A~10A |
|||
standby Current |
≤10mA |
|||
|
Port
|
power Port |
BATT,ACC,GND |
||
speaker Port |
4x45W 4 channels stereo |
|||
|
AUX |
2 video output,1 video input,1 rear camera input,1 front camera input,1 stereo audio output,1 Subwoofer output,1 stereo input,1 DVR input |
|||
steering wheel port |
2 steering wheel AD interfaces,1 IR infrared input interface |
|||
USB |
1 USB port |
|||
iPod |
1 iPod ports |
|||
antenna control/amplifier |
1/1 |
|||
headlight detection/brake test |
1/1 |
|||
Reverse/phone mute detection |
1/1 |
|||
|
Supporting Formats |
DVD/SD/USB |
MP4/ DVD/ VCD 1.0/ 1.1/ 2.0/ 3.0 versions, DVD, CD-R/ CD-RM/ MP3/WMA/ JPEG/ WMV/ MTV/ AVI/ MPG/RMVB |
||
|
Radio |
FM:65MHz~108MHz |
choose frequency according to the local radio system |
||
AM:522KHz~1720KHz |
choose frequency according to the local radio system |
|||
Digital TV |
adapt to different countries’ standards & ur requirements |
|||
A-TV |
PAL-I/DK/BG,SECAM-DK/BG,PAL-M,PAL-N,NTSC-MN |
|||
GPS |
Band rate:9600bps COM:2 |
|||
|
Bluetooth |
Support OPP,OBEX,SPP, A2DP, AVRCP,Handset and Handsfree Profiles bluetooth protocol |
Standard:Bluetooth2.0, Class II |
||
Steering wheel |
support high/low resistance steering wheel, 0V~5V Simulate keystrokes voltage. |
Hight/low resistance automatic switching |
||
