High performance laminating doors production line
We are manufacturer of woodworking machines, we offer most suitable proposals for furniture factory.
Sliding table saw
Parameters:
Max cutting length |
2500-2800mm |
Cutting thickness |
0-65mm |
Main blade speed |
4500 / 6000r.p.m |
Main Blade size |
(250-400) * 30mm |
Scribing blade speed |
7000rpm |
Scribing blade size |
120 * 20mm |
Total motor power |
4.75kw |
Dimensions |
2600 * 2500 * 810mm |
Machine weight |
800kgs |
CNC router
Parameters:
Working area |
1300*2500*200mm |
Motor |
Stepper motor and driver |
Spindle |
Three Italy 4.5kw protect air cooling spindle |
Table |
Vacuum table |
Rails |
Taiwan CSK square rails |
Controller |
NC studio control system |
Dimensions |
3200 * 1800 * 2300mm |
Weight |
1300kgs |
Sanding machine
Parameters:
Model |
Automatic R-R-R |
Type |
Profiled surface sanding machine |
Custom processing |
YES |
The maximum process length |
350--5000 (mm) |
Rated power |
13.47 (kw) |
Dimensions |
3100 × 1300 × 1500 (mm) |
Parameters:
Model |
Automatic, double table |
Working area |
3000*1350mm |
Working pressure |
Vacuum≤-0.09MPa |
Processing thickness |
60mm |
Power |
15kw |
Dimensions |
9300*1900*1400mm |
Weight |
1500kgs |
Edge banding machine
Parameters:
Electric lift |
support |
Total power |
14.5KW |
Feed speed |
12-20m / min |
Sheet thickness |
10-60mm |
Edge thickness |
0.4-3mm |
Sheet width |
≥80mm |
Working pressure |
0.6MPa |
Dimensions |
5397mmX100mmX1600mm |
Boring machine
Parameters:
Plate size |
1250 500mm |
Maxi pressure |
50 t (1.6kg / cm 2) |
Hydraulic system pressure |
210kg / cm 2 |
Plate max distance |
1000mm, 1300mm |
Cylinder |
dia 110mm/pcs |
Hydraulic motor power |
3kw |
Dimensions |
2940X1250X3000mm |
Weight |
2300kgs |
Our storage:
1. how should I pay for my order ? what is the procession of this purchase ?
we accept TT by bank. you can do 40% prepayment at first, then we will start to make production. when the machine is ready , we will take pictures to you, and then you can do the ballance. after we got your payment. i will send the machine to you.
2. how about your service after sales ? can your engineer speak fluent english ?
we offer the service from you got the machine, including how to install the machine, how to use machine. how to let machine work. and so on. usually we will teach you how to do by email or by skype . our engineer has many years of experience for cnc machine service . so he can slove the problem in short time.
3.Are you a factory or trading company?
We are the manufacturer . as only the machine made by ourself ,quality can be trusted, and most important thing is we can do better serivce after sales. we know how to fix the problem in each parts easliy. so welcome to visit to our factory
