Wood Cutting Panel Table Saw
US$ 1,400 - 3,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Table Panel Saw
Use:
Woodworking
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin etc.
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic 2mm Pvc Edge Banding , Italy Edge Banding Machine for Furniture Supplier's ChoiceUS$ 2,500 - 8,000MOQ: 1 Set -
Woodworking Doring Machine for Drilling CabinetUS$ 9,000 - 10,000MOQ: 1 Set
-
Wood Working Machines Cabinet Door Sanding Machine , Wood Panel Sanding Machine for MDF , Particle BoardUS$ 4,500 - 7,000MOQ: 1 Set
-
Cabinet Drilling Machine , Horizontal Directional Drilling Machine for SaleUS$ 9,000 - 10,000MOQ: 1 Set
-
European Quality Laminate Press Machine Plywood , High Pressure Wood Laminate MachineUS$ 4,500 - 10,000MOQ: 1 Set
Condition
New
Type
Table Panel Saw
Use
Woodworking
Style
Horizontal
Place of Origin
Shandong, China
Brand Name
Sange
Model Number
SG-2837
Usage
Woodworking
Voltage
220V/380V
Power(W)
5.5kw
Dimension(L*W*H)
2800*375mm
Weight
500KG
Certification
CE,ISO
Warranty
12 Months
After-sales Service Provided
Engineers available to service machinery overseas
China high precision Wood cutting panel table saw
Features of woodworking sliding table saw:
1. Max. adjustable angle of main saw blade: 45° or 90°
2. Slide rail type: Altendrof structure (A), round rod structure(D) or linear structure(Z).
3. Saw blade lifting and tilting system (manual or electric)
4. Sliding table length from 1500mm to 3800mm (usually we have 1600, 2200, 2600, 2800, 3000, 3200, 3800mm).
5. All the sliding table saw have CE certification.
Technicial Parameter:
| Dimension of sliding table | 2800*375mm |
| Gross cut capacity | 2800mm |
| Width of cut between saw blade and rip fence | 1250mm |
| Saw blade diameter | 300mm(250-300) |
| Height of cut (diameter:300mm) | 85mm |
| Height of cut with saw blade 300mm at 45 angle | 55mm |
| Speed of main saw spindle | 4000/6000rpm |
| Main spindle diameter | 30mm |
| Tilting saw blade | 45 degree |
| Main motor | 5.5kw |
| Scoring saw blade diameter | 120mm |
| Speed of scoring saw blade | 8000r/min |
| Scoring spindle diameter | 20mm |
| Scoring motor | 0.75kw |
| Net weight | 800kg |
| Gross weight(with wooden package) | 950kg |
| Overall dimensions | 2800*3150*900mm |
Applications:
The woodwoking sliding table saw is apply to processing all kinds of fiberboards,flake boards,
wood-based panels,ABS boards,PVC boards,acryl glass board and the solid wood etc,or the
panels with similar hardness.
