dvb-s dvb-s2 modulator ip (ASI/IP IN,DVB-S2 RF out,950-2150mhz 17.2-39.9mbaud/s,qpsk&8psk)
dvb-s dvb-s2 modulator ip
ASI DVB-S/S2 Modulator (950-2150 MHz)
Overview
ASI DVB-S/S2 modulator supports ASI input,RS coding,convolution interleaving and DVB-S(QPSK)/DVB-S2(QPSK/8PSK) modulation channel processing, it gives RF signal output.
Technical Specification
Input Interface | 1* ASI IN, (DVB standard, BNC interface) | |
1*100mbps IP(TS over UDP) port | ||
Output Interface | RF, option: F-head or N-head | |
Modulation Mode | DVB-S(QPSK)/DVB-S2(8PSK) | |
DVB-S2 | QPSK: 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 | |
DVB-S | QPSK: 1/2, 2/3, 3/4, 5/6, 7/8 | |
Roll-off Factor | 0.2, 0.25, 0.35 | |
Impedance | 75Ω | |
Output Frequency | 950~2150MHz (1khz step) | |
Symbol Rate | 17.2~39.99 Mbaud/s | |
Error-Correcting Codes | RS code188/204 | |
MER | ≥35Db | |
Output Level | 80~104Dbv | |
Level Attenuation | -20dBm~0dBm (0.5db step) | |
Management | network RJ-45, 10/100M | |
Keyboard+LCD | ||
General Features | Size | 410mm×280mm×44mm |
Temperature | 0~45°C (Operation); -20~80°C (Storage) | |
Power | 100-240VAC, 50Hz, 25W | |
Order Guide
4112 | ASI in, DVB-S/S2/QPSK/8PSK RF out (950-2150MHz,1-45mbaud/s) |
4122 | ASI/IP in,DVB-S RF out(950-2150MHz,17.2-39.9mbaud/s,qpsk/8psk) |
Network Management:
Modulator setting:
Developing :
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
