cnc router wood carving cnc turning 3d furniture wood carving cnc router machine stone carving machine

Name: cnc router wood carving cnc turning 3d furniture wood carving cnc router machine stone carving machine
Brand: Senke
Price: USD $2,250 - 5,590 / Set

FOB Price

USD $2,250 - $5,590 / Set

1 Set(Min.Order)

Supply Ability 220 Set / Sets per Month
Port Tianjin/Qingdao
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	CNC or Not:	CNC	Place of Origin:	Shandong, China
Brand Name:	Senke	Model Number:	SKW 1325	Voltage:	220/380/410V
Power(W):	3.0KW(4.5 5.5 for choice)	Dimension(LWH):	13002500200mm	Weight:	1200KGS
Certification:	CE,ISO,FDA,SGS,CO	Warranty:	two years	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

cnc router wood carving cnc turning

Product Description

cnc router wood carving cnc turning

Features

1.Welded structure by thick profiled steel stabilized under high temperature, ensures ,minimum distortion, excellent rigidity and powerful strength

2. Vacuum working table optional,with double cavities and Bakelite material with high absorption power.

3.adopt domestic water cooling spindle of big power(option:air cooling spindle)
4.high accuracy, long service time, steady movement and good starting performance, great torque, fulfilling the advantage of working with fast speed and low noise.

Parameters:

Model	SKW-1325 / SKW-1325/SKW-1525etc
X,Y,Z axis workin g area	13002500200mm
Machine size	300521001600mm
X,Y movement	Rack and pinion
Z movement	Ballscrew transmission
Guide	Taiwan HIWIN/PMI 20 square rails(round rails optional)
Max idling speed	40000mm/min
Max engraving speed	23000mm/min
Spindle power	3kw/4.5kw/6kw watercooling/aircooling (choose)
Spindle speed	18000-24000rpm
inverter	3.7KW/7.5KW(depend on spindle choose)
Drive motors	Stepper motors (servo motors and drviers optiona)
drivers	Leadshine
Control system	NC-Studio as standard/DSP
Working voltage	1220V/380V or customized
Command code	G code
software	Artcam,type 3,etc
collet	ER 25-32
Packing dimension	3.12.11.82M
weight	1260kgs/1350kgs
Standard equipment included	1.automatic oil injection system 2.Tool sensor 3.vacuum table,5.5kw vacuum pump

Applications:

Woodworking industry: wood crafts, picture frames cutting, handicraft carving wave plates, wooden door production and processing (density board and particieboard, sandwich plate, cutting, making violin surface, solid wood furniture, carved wood art murals carved, guide plate processing, avoid lacquer carved door, cabinet door, craft wooden door, wenqi door, screen, PP plate cutting, the process window processing, aluminum plate cutting, calligraphy carving made three-dimensional wave board processing, wooden door, screen, process window, small handicraft processing, large area of plate plane sculpture, secondary processing of various kinds of wooden products, furniture products.

Sample pictures

Machine work video:)

------Some laser and plasma working video for your check :)

Laser cutting machine cut on wood :https://youtu.be/2EzHKQHgP_w

Laser prints machine working video : https://youtu.be/iB3mS_6N1Ps

Laser cutting machine on wood: /watch?v=pwPzhhx0GrE

Laser engraving machine on acrylic video: /watch?v=AUiP-_TfOP4

Plasma cutting machine on iron: https://youtu.be/C4Bo9R2hpBk

Plasma cutting machine cut iron round shape: /watch?v=y43Tlr3Hbms

------CNC router machine working video for your check : )

Cnc moulding&engraving machine on foam :https://youtu.be/Jr_A_vw51FY

Cnc router with ATC in disk engraving machine: https://youtu.be/sYuP-4dlJuU

Cnc machine with ATC in linear engraving on wood :https://youtu.be/2aBXJwkOpbM

Cnc cutting machine professional for glass:/watch?v=4BLk3XsURvU

Cnc multi heads engraving on sofa leg:/watch?v=iKvj7Nd86hQ

Cnc with three spindles auto tool change: /watch?v=4urGnn33B64

Cnc engraving machine with rotary(olive nut): https://youtu.be/tmCRK9UHuVM

For Trade Assurance

Senke CNC Machine CO.,ltd is the direct manufacture of cnc router and laser machine trade company.

We always ensure the safety of your cooperate with us.

FAQ

1. Q: Are you a factory or trading company?
A:We are a manufacturer with export license

2. Q: Can you do OEM?

A: Yes, we can do OEM products.

It's no problem.

3. Q: How does your factory do regarding quality control?
A: "Quality is priority? Senke people always attach great importance to quality controlling from

the very beginning to the very end:
1).All raw material we used are environmental-friendly;
2).Skillful workers care every details in handling the producing and packing processes;

3).Quality Control Department specially responsible for quality checking in each process.

4. Q: what kind machine do you offer?
A: we senke professional wood,marble,metal,foam etc various cnc routers.at the same time,

meet customer requirements,laser cutting/marking machine, dot peen marker available.

5. Q: what kind materials your machine can process?

A: according to parts adopt,the senke cnc router suitable for all kinds of materails,including

metals and non-metals,such as types of wood,marble,granite,metals(aluminum,brass,cooper,

steel etc),foam(EPS),PVC,PCB board,double-colour board,glass,tiles etc etc.

6. Q: how shall i choose the models?
A: different models suitable for different materials,just told us,what your mainly materials,what the
materials size and what the mainly job need the machine do. we senke engineer will supply you
the best solutions.
