Overview
IP multiplexer scrambler supports IP/multicast TS-over-UDP input and 4*ASI(or 4*MPTS TS IP/UDP) output. It supports multiplex and scramble to output 4×MPTS directly. It supports 4×CAS/SMS simulcrypt. It suits 1U rack and can be configured by front panel LCD and NMS (network management software).
Technical Specifications
Input |
IP Port |
1000mbps/gigabit, 32/64×multicast IP stream |
Output |
Model 3105 |
4*ASI:DVB standard, BNC interface |
Model 3107 |
4*MPTS multicast: 1000mbps/gigabit |
|
Multiplexer |
from the input 32/64×multicast IP stream PID filter and PID re-mapping PSI/SI edit and NIT table inserts Real time monitoring PCR re-adjustment and correction |
|
Scrambler |
support 4×CAS/SMS; head-end implementation of DVB simulcrypt (ETSI TS 103 197 V1.4.1) |
|
Control |
IP remote |
NMS (Ethernet Port, RJ-45) , 10/100m base-TX, |
|
Front panel |
Keyboard + LCD |
General Features |
Size |
410mm×280mm×44mm |
Temperature |
0~45°C(Operation); -20~80°C(Storage) |
|
Power |
100-240VAC, 50Hz, 25W |
Order Guide
3105 |
IP ASI Multiplexer Scrambler(IP-UDP/multicast Gigabit in,4*ASI out) |
3107 |
IP Multiplexer Scrambler(IP-UDP/multicast Gigabit in,4*MPTS-IP/multicast out) |
3106 |
ASI Scrambler Multiplexer(8*ASI in,ASI out) |
Network Management Software
TS Multicast UDP 64*input:
multiplexer:
output setting:
scrambler(cas ecmg,emmg) setting:
nit edit:
PID passthrough:
Developing :
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
