heavy duty machines and equipments cnc router, 1325 ATC cnc woodworking center, cnc wooden router
Machine Features:
1)linear type atc tool magazine, install 8-12 different kinds of woodworking tools(depending on customers' needs). It only needs 4s to change tools ,faster than any carousel ATC CNC Router
2) Adopts whole steel structure,using high temperature tempering destressing to precision machining, guarantee the machine service life
3)imported 9kw automatic tool changing spindle, big power, low noise, low fault rate
4)imported AC servo motor,high precision
5)imported original linear guideway
6)imported precise helical wheel,helical tooth,high precision and fast speed
7)Force industrial controlling system,high precision,perfect stability
8)imported planetary reduction gears,high precision,low noise,long service life
9)automatic alarm,automatic oiling,automatic tool-setting
10) Many optional configuration and OEM service available. According to your different requirement, configurations will be offered. OEM service is available for you.
Parameter of cnc router atc | |
X,Y,Z working area |
1300*2500*200mm |
X,Y,Z Traveling positioning accuracy |
±0.03/300mm |
Lathe bed frame |
heavy lathe bed |
X,Y Structure |
Rack |
Z Structure |
Taiwan TBI Ball Screw |
Table surface |
Vacuum table |
motor |
Japan Yaskawa servo motors |
Working speed |
0-80000mm/min |
Spindle power |
Italy 9.0KW air cooling spindle |
Spindle speed |
0-24000RPM/min |
Spindle inverter |
Delta inverter |
Working voltage |
AC380V/220V |
Operation system |
Taiwan syntec control system |
Command language |
G code |
X,Y Resolution |
<0.02mm |
Running environment temperature |
0-45°C |
Dust collector |
yes |
SG-1325-c3-10 Linear Type ATC CNC Router
Jinan Sange CNC have researched and produced the linear type ATC CNC Router using the latest technology. It only needs 4s to change tools ,faster than any carousel ATC CNC Router, Ultra-low prices, stable performance, cost-effective, easy maintenance, etc. It is very suited to cabinet door/sliding room/painting door/panel furniture manufactory.
furniture: panel furniture, cabinet, sliding door, soft pack board, wooden door, office furniture
woodworking Industry: voice box, game cabinet, computer desk, sewing table, instrument
panel processing: insulating material, plastic, PCB, train inner structure, bowling track, compact-panel ,epoxy resin, ABS,PP,PE etc
decorating industry: acrylic, PVC,MDF board, organic glass, plastic, aluminum/copper soft sheet metal ornamental milling cutting processing
