6090 Cheap Desktop Stone Wood Marble Mdf Metal Engraver 4 Axis Cnc Router for Metal Brand New Milling Machine With Cnc

6090 Cheap Desktop Stone Wood Marble Mdf Metal Engraver 4 Axis Cnc Router for Metal Brand New Milling Machine With Cnc photo-1
6090 Cheap Desktop Stone Wood Marble Mdf Metal Engraver 4 Axis Cnc Router for Metal Brand New Milling Machine With Cnc photo-2
6090 Cheap Desktop Stone Wood Marble Mdf Metal Engraver 4 Axis Cnc Router for Metal Brand New Milling Machine With Cnc photo-3
6090 Cheap Desktop Stone Wood Marble Mdf Metal Engraver 4 Axis Cnc Router for Metal Brand New Milling Machine With Cnc photo-4
6090 Cheap Desktop Stone Wood Marble Mdf Metal Engraver 4 Axis Cnc Router for Metal Brand New Milling Machine With Cnc photo-5
6090 Cheap Desktop Stone Wood Marble Mdf Metal Engraver 4 Axis Cnc Router for Metal Brand New Milling Machine With Cnc photo-6
US$ 3,999 - 5,900 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
senke
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin shanghai qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name senke
Model Number SKM-6060
Rated Power 2.2kw
Engraving Speed depend on model
Main Axle Rotational Speed 0-24000RPM
Feeding Height 150mm
Milling Cutter Diameter depends on spindle
Application all kinds of metals
Dimensions 600*600
Weight 290kgs
Certification CE
Warranty 2 years
After-sales Service Provided Engineers available to service machinery overseas

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc

Product Description



Main features:

1. The machine whole cast iron body, chassis stability high load bearing, used for a long time never deformation, ensure the accuracy of metal processing requirements

2. Special metal spindle optional spindle has permanently power, long life, big power, the machining accuracy increase of 20%

3. Adopt imported ball screw, occlusive close, effectively meet the precision requirement of and improve the metal processing

4. taiwan square rails,support moving table,improving precision greatly,senke sample tested minimum forming 0.5 MM!



Technical Parameter

Model

                    SKM-6060

Working area (X*Y*Z)

                  600*600*150MM

Body structure

                  Iron casted,strong enough for metals work

X, Y Structure

                     Taiwan HIWIN square rails

Z Structure

                      Taiwan TBI ball screw

X, Y Resolution

                         <0.03mm

Max Moving Speed

                       18000mm/min

Max Engraving Speed

                       10000mm/min

XYZ traveling positioning accuracy

                       ±0.01mm

XYZ repositioning accuracy

                        ±0.01mm

Spindle power

                      2.2kw metal professional use spindle

Spindle Speed

                       0-24,000rpm

Voltage

                     220v/380v(choice)

Drive type

                        Servo motors and drivers

Working  Dictate

                        G Code

Operating system

                      DSP (A11) model control

Interface

                         USB

Running Environment

                     Temperature: 0℃~45℃

Table

                     t-slot table with clamps

Package size

                     1.3*1.3*1.7M

G.W

                     290KGS

 Applications:

Advertising (metal plates, hot stamping plate), seals (chapters atoms, copper), signs, electronic, handicrafts, mold and decoration, can be for copper, aluminum, brass, iron, stainless steel, the atomic chapter, battery carbon plate, aluminum-plastic plate, Yang carved, Yin carving, line carve, tone, artistic relief, such as processing, support circular arc bottom, bottom tip, flat characters such as sculpture

 Parts show

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc



Samples

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc



6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc



Packaging & Shipping



6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc

Company Information

 6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc



Our Services

Operation

all senke machine sending with software CD,software manual,teaching video,machine operate manual,packing list,if you want view first,please kindly contacted we seller directly,we send by email

Videos

if you want check,how the machine work,please kindly contact we seller,we will send to you senke router working video.

Training

we senke team was constituted by skilled staff,anyone of them with years experience,can operate all style control system machine skilled and adept,if you needed,we engineer oversea services available,detailed charges please contacted we seller,also if you like,welcome to us,in we factory,the training service itself free.

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc

6090 cheap desktop stone wood marble mdf metal engraver 4 axis cnc router for metal brand new milling machine with cnc

FAQ

Q.what kind materials your machine can process?

according to parts adopt,the senke cnc router suitable for all kinds of materails,including metals and non-metals,such as types of wood,marble,granite,metals(aluminum,brass,cooper,steel etc),foam(EPS),PVC,PCB board,double-colour board,glass,tiles etc etc.

Q.how shall i choose the models?

different models suitable for different materials,just told us,what your mainly materials,what the materials size and what the mainly job need the machine do. we senke engineer will supply you the best solutions.

l me about the controller?

the commonly market use for cnc router including,nc-studio,mach 3,DSP,SYNTEC,LNC etc,according to models choose,senke adopt nc-studio as standard

Q.what other accessories included?

please kindly contact we seller,they will supply you the detailed senke router packing list.



Other machine modle
