Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting

Name: Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting
Brand: Sange
SKU: 116098613
Availability: InStock

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting thumbnail-1

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting thumbnail-2

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting thumbnail-3

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting thumbnail-4

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting thumbnail-5

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting thumbnail-6

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting photo-1

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting photo-2

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting photo-3

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting photo-4

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting photo-5

Hot Sale Atc Cnc Router Wood Engraving Machine for Furnitures Aluminum MDF Cutting photo-6

US$ 1,500 - 5,500 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

CNC

Place of Origin:

Shandong, China

Contact Supplier Request Quote Chat Now

Jinan Sange CNC Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Tianjin Shanghai Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not CNC

Place of Origin Shandong, China

Brand Name Sange

Model Number SG-1218

Voltage 3phase AC380V/50HZ

Power(W) 4.5KW

Dimension(L*W*H) 1200*1800*200mm

Weight 450KG

Certification CE ISO9001,FDA,SGS,CIQ

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Hot sale atc cnc router wood engraving machine for furnitures aluminum MDF cutting

Technicial Parameter

Item	Wood engraving machine
X,Y,Z Working Area	12001800200mm(can be customized)
Table Size	1200*1800mm
X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
X,Y,Z Re-positioning Accuracy	±0.03mm
Table Surface	Aluminum/Vacuum and T-slot Combined (Option: T-slot Table)
Frame	Welded Structure
X, Y Structure	3 axis ball screw, Taiwan CSK Rail Linear
Z Structure	Taiwan Hiwin Rail Linear Bearings
Max. Rapid Travel Rate	50000mm/min
Max. Working Speed	25000mm/min
Spindle Power	1.5 kw
Spindle Speed	0-24000RPM
Drive Motors	Stepper/Servo motor and drive( Japan YASKAWA/Panasonic)
Working Voltage	AC380V/50/60Hz,3PH (Option: 220V))
Command Language	G code
Operating System	Original NC studio/DSP/MARCH3 controller system
Collect	ER11
X,Y Reporsition	<0.03mm
Software Compatibility	Type3/Artcam/ Software (Option: UcancameV9 Software)
Dust collector	2.2/3 KW (single bag/double bags)

Main Parts of wood engraving machine

1. Whole machine is welded with seamless steel structure, with aging treatment.

2.Adopt Taiwan HIWIN high precision linear orbit. X Y Z axis adopts Germany and Taiwan ball screw,with high precision and long life time.

3. Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai etc.

4. The function of re-carving after break point and power failure. Has the function of forecasting process time.

5.Can choose updated DSP / Mach 3 or Original Nc Studio control system.

6. We provide the DSP operating instruction in English, a set of cutters, software, necessary tools and accessories for free.

7. Can process wood,stone,acrylic,copper,PVC,MDF,PCB……

Application of wood engraving machine

1.Furniture: wooden door and furniture, windows, tables and chairs,cabinets and panels, 3D wave plate,MDF,computer desk,musical instruments,etc.
2.Advertising: billboard, logo,sign,3D characters cutting,acrylic cutting,LED/neon channel,literal-hole cut,light-box mold,stamp,mound,etc.
3. Board processing: insulation, plastic chemical components, PCB, car body, bowling track, ABS, PP, PE, etc.
4. Decoration: Acrylic, PVC, MDF, glass, plastic and soft metals such as copper and aluminum.
