ip to rf converter scrambler modulator (TS IP/multicast gigabit in,4*DVB-C RF out)
in:ASI/DVB-S-S2/IP/DVB-C
out:IP/ASI/RF modulator
Multiplexer/scrambler
ip to rf converter
4IN1 Multicast-IP/UDP QAM Modulator with MUX-Scrambler
Overview
4IN1 IP QAM Modulator with MUX-Scrambler supports Multicast-IP/UDP input and 4×RF output. The input IP signal can be sent to signal processor and be converted to TS (transport stream). It integrates multiplexer, scrambler and QAM/DVB-C modulator. It supports 4 CAS/SMS SimulCrypt.It suits 1U rack and can be configured by front panel LCD and NMS (network management software).
Technical Specifications
Input |
IP Port |
TS over UDP, Gigabit/1000mbps |
|
Output |
Interface |
4in1 RF, F-head |
Impedance |
75Ω |
|
Constellation |
16, 32, 64, 128, 256 QAM |
|
Symbol Rate |
5~9 Msps, 1ksps step |
|
Error-Correcting |
RS code188/204 |
|
MER |
≥40dB |
|
BER |
0 |
|
Output Level |
85~105dBV |
|
Level Test Port |
65~85dBV |
|
Level Attenuation |
-20dBm~0dBm (per carrier), 0.5dB step |
|
Frequency |
47MHz~870MHz |
|
|
Multiplexer |
from the input 32/64×Multicast-IP |
|
Scrambler |
support 4×CAS/SMS DVB simulcrypt (ETSI TS 103 197 V1.4.1) |
Control |
IP remote |
NMS (Ethernet Port, RJ-45), 10/100m base-TX, |
Front panel |
Keyboard + LCD |
|
|
General Features |
Size |
482mm×280mm×44mm |
Temperature |
0~45°C (Operation); -20~80°C (Storage) |
|
Power |
100-240VAC, 50Hz, 25W |
Order Guide
4154 |
TS Multicast IP in, 4×RF/QAM/DVB-C out |
4174 |
8×ASI in, 4×RF/QAM/DVB-C out |
4125 |
6*DVB-S/S2+6*ASI in, 4×RF/QAM/DVB-C out |
4135 |
8*DVB-S/S2+3*ASI+1*IP in, 4*RF/QAM/DVB-C+4*MPTS IP out |
Network management software
Device type on network management software:
modulator output setting:
multiplexer:
input ip address setting:
simulcrypt scrambler setting:
nit edit :
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
