mpeg-1 layer 2 audio encoder
4IN1 mpeg-1 audio Encoder
in:4 analog audio
out:ASI
bitrate:64kbps to 384kbps
sample:48khz,44.1khz,32khz
4IN1 MPEG-2 SD Encoder
Overview
4IN1 MPEG-2 SD Encoder supports SD MPEG-2 video and MPEG-1 audio encoding. It has 4×CVBS video, 4 pairs of unbalanced audio and 1×ASI (BNC (MUX)) input interfaces, and can multiplex the input signal (TS) to generate DVB transport stream (TS/ASI) and IP (TS over UDP) output. The encoder suits 1U rack and can be configured by front panel LCD and NMS (network management software).
Technical Specification
Input |
Video Signal |
4×CVBS, BNC interface, level 1.0 Vp-p |
Audio Signal |
4 pairs of unbalanced audio, BNC interface, level 2.0 Vp-p |
|
ASI |
MPTS/SPTS, DVB standard (mux), BNC interface |
|
Video |
Standard |
support 1/2D1, 2/3D1, 3/4D1,9/16D1 |
Encoding |
comply with ISO13818 (MPEG-2) MPEG-2 coding adopt MP@ML (4:2:0) MPEG-2 Adaptive Field Frame (AFF) MPEG-2 Field-Based (FB) |
|
Format |
PAL/NTSC |
|
|
BitRate |
1.0~15Mbps continuously adjustable per channel |
Audio Coding |
Sampling |
32KHz, 44.1KHz, 48KHz |
Code Rate |
32, 48, 56, 64, 128, 192, 256, 384, 448Kbps |
|
Property |
MPEG-1 Layer2, 1×stereo or dual-channel |
|
Output |
2×ASI |
1 as mirror, DVB standard, BNC interface |
IP(1808 model) |
100mbps RJ45,TS over IP/UDP/1*MPTS/4*SPTS |
|
|
Total bitrate |
1-90mbps |
Control |
NMS (Ethernet port, RJ-45), Keyboard + LCD |
|
General Features |
Size |
482mm×280mm×44mm |
Temperature |
0~45°C(Operation); -20~80°C (Storage) |
|
Power |
100-240VAC, 50Hz, 25W |
|
Order Guide
1108 |
4*AV in, ASI+IP/UDP(1*MPTS/4*SPTS) out |
1103 |
4*AV+1*ASI in, ASI out |
1808 |
MPEG-2 8IN1 IP encoder(8AV+ASI in,ASI+IP(1*MPTS/8*SPTS) out |
|
Network management software
multiplexer output setting:
video and audio setting:
asi in multiplexer:
mpts/spts ip out:
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
