4 Channels IP-ASI Converter/ ip multiplexer scrambler 4-channel

4 ASI Output IP MUX Scrambler

Overview

4in1 IP MUX-Scrambler is a cost effective integrated IP multiplexer and Scrambler .It is designed by SoChuang Company.

This device support 64 IP input. And IP signal has been sent to signal processor after synchronized process. After

multiplex and Scramble of the signal processor, then 4 ASI output directly. It supports 64 channel IP inputs. Hence

,one peice 4 in 1 IP MUX-Scrambler can work as 4 stand alone scrambler, significantly reducing the network operators’

head-end cost. Also it can support local and remote control to set its working parameters.

Features

u  Meet DVB standard channel coding;

u  8M cache, anti-burst stream;

u  Meet the DVB Commonly Used Scrambling Algorithm, support simulcrypt model, compatible with multiple

conditional access (CA) system

u   Configurable PID filter, re-mapping, PSI, SI information synchronization update;

u   Support NIT table inserts;

u   Through the network system for status monitoring;

u   Support rate adaptive, PCR re-adjustment function and re-marking function;

u   Package format: automatically adapt to 188/204 package format;

u   Local and remote control;

u   LCD display in Chinese and English, easy and flexible to operate;

u   High reliability design, stable operation;

Technical Specifications

Principle Chart

Network Management

P1: IP IN Setting

P2: Multiplex Setting

P3: Scrambler Setting

P4: Edit NIT

P5: PID Passthrough
