China Wood MDF door 2d and 3d engraving machine rotary wood carving machine
SKW-1325 cnc router Features:
2. X,Y axes transmission with gear rack, Z axis transmission with imported ball screws, ensures stable and smooth movement of the machine.
3. flat and rotary work ,two functions in one set,save cost and time
4. Applicatin of driver with high definition subdivision ensures fast speed and high accuracy.
5. High power spindle, brushless, water cooling/air cooling, working vigorously with low noise.
Technical parameters:
Model |
SKW-1325V/SKW-1530V/SKW-2030V etc |
X,Y,Z axis workin g area |
1300*2500*200mm |
Machine size |
3005*2100*1600mm |
X,Y movement |
Rack and pinion |
Z movement |
Ballscrew transmission |
Guide |
Taiwan HIWIN/PMI 20 square rails(round rails optional) |
Max idling speed |
40000mm/min |
Max engraving speed |
23000mm/min |
Spindle power |
3kw/4.5kw/6kw watercooling/aircooling (choose) |
Spindle speed |
18000-24000rpm |
inverter |
3.7KW/7.5KW(depend on spindle choose) |
Drive motors |
Stepper motors (servo motors and drviers optiona) |
drivers |
Leadshine |
Control system |
DSP / NC-Studio as optional |
Working voltage |
220V/380V or customized |
Command code |
G code |
software |
Artcam,type 3,etc |
collet |
ER 25-32 |
Packing dimension |
3.1*2.1*1.82M |
weight |
1260kgs/1350kgs |
Standard equipment included |
1.automatic oil injection system 2.Tool sensor 3.vacuum table,5.5kw vacuum pump |
Main parts:
1. Rotary axis can be add
2. water cooling spindle or aircooling spindle can optional
3.NC-studio or DSP control system
4.Vacuum worktable or T-slot worktable
Applicable industry:
1. Timber/wood/foam/bamboo cylinders, etc.
2. Flat board and rare shaped work piece with material like timber, MDF, plastics, soft metal, acrylic,PVC and so on.
Double paking of protective film and fumigation-free wooden case:
Service:
1 We will provide the user a CD to study the machine installation and commissioning.
2 Our technicists can give user online guide.
3 The user can by call or email us any problems at any time.
4 After-sales service.
Two year warranty for machine maintenance, for equipment maintenance over the warranty period is clearly marked.
Questions and answers:
1,How about the documents after shipment?
After shipment, we will send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
2,How long is the delivery time?
For standard machines, it would be 5-7 days; For non-standard machines and customized machines according to clients specific requirements, it would be 10 to 15 days.
3,Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
4,How is the packing?
Waterroof plastic film package with foam protection in each cornerSolid Seaworthy Wood Box Package with Steel Belt Save space as much as possible for container loading.
Our factory and work team:
Certificate:
thanks for your interest in our machine, please contact me directly as following:
Jinan Senke CNC Machine Co.,Ltd.
Web:
Wechat/WhatApp/Line: +86 15098837889
Tel: +86 531 88099059
Fax: +86 531 88099059
Skype: senkerouter.juan
