Multi function 4 heads wood sofa legs cnc wood carving machine for sale We pay attention to any detail of our Every set CNC Router Machine,
we provide the best Abroad Service for Every Customer !
Performance:
1. four axis machine, with 4 Rotaries and 4 spindles, which can work at the same time or independently, and every one's max effective working area is 300mm(diameter) by 1500mm(length).
2. With Scanner or designed photo, it can do any 3D Engraving and 2D Engraving .
3. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
4.Has the 4th rotary which is used for engraving cylinder workpiece.
5.Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/ Castmate/Wentai etc.
6.Has the function of re-carving after break point and power failure
7. Adopting advanced YASAKWA servo motor and DSP(A18) control system .
Technical parameters:
Description |
Parameter |
4th rotary axis max diameter |
300mm |
Machine dimension |
1800mm*1450*1450mm |
Resolution |
0.01mm |
Lathe structure |
Seamless welded steel structure |
X,Y structure |
Rack and pinion transmission, Hiwin square guide rail |
Z structure |
Imported ball screw |
Max. idling speed |
35m/min |
Spindle motor power |
2.2 KW |
Spindle rotate speed |
0-24000r/min |
Working voltage |
AC380V/50Hz or can be customized |
Working mode |
Stepper motor |
the control system |
DSP(A18) control system/ Option NC Studio |
Cooling mode |
water-cooling |
Head |
4 heads |
Rotary |
4 rotaries |
Machine main parts:
Applicable industry and material:
This item is very suitable for furniture bulk production such as desk legs/stair handrails and other column /cylinder products,it also can easily engrave 360 degree Human body,Buddhist statue,sculpture,and other art works.
Samples for reference:
Welcome you visit our more product information from below website links ~~
Youtube website Link : /c/LiuJuan
Facebook website Link : /juan.liu.129
Google Plus website Link : /+LiuJuan
Double paking of protective film and fumigation-free wooden case:
Service:
1 We will provide the user a CD to study the machine installation and commissioning.
2 Our technicists can give user online guide.
3 The user can by call or email us any problems at any time.
4 After-sales service.
Two year warranty for machine maintenance, for equipment maintenance over the warranty period is clearly marked.
Our factory and work team:
Certificate:
