Frac head /goathead fracturing equipment Frac stack
Frac head /goathead fracturing equipment Frac stack
Goathead frac adaptor is the equipment often used on frac tree and frac stack during fracturing work,which is often in studded and flange-end connections
Goathead frac adaptor is the equipment often used on frac tree and frac stack during fracturing work,which is often in studded and flange-end connections. Frac head are own various sizes and inlets used to tie multiple frac lines into the frac tree we can also design many type of the frac head as per the requirements.
Fracturing head provided by JEFA Machinery are field proven products which strictly designed and manufactured according to API 6A Standard and API Spec Q1.
Goathead frac adaptor information:
Our Frac heads are available in DD and EE trim,customers may customize their purchase through the following data:
• Working Pressure
• Type of Top Connection
• Type of Bottom Connection
• Through-Bore Minimum Width
• Number of Side Connections
• Side Connection Branch Angle
• Side Connection Branch, Type, and Pressure Rating
Jefa’s customizable Goathead frac adaptorallow customers to design their ideal frac head for reliable and consistent performance on their frac system.
| Fracturing Head | ||
| Item | Description | Specification |
| 1 | 4-1/16'',10M X 4 outlets (3-1/16'',10M) | PR1,PSL3,L-U |
| 2 | 4-1/16'',10M X 4 outlets (4-1/16'',10M) | PR1,PSL3,L-U |
| 3 | 5-1/8'',10M X 4 outlets (3-1/16'',10M) | PR1,PSL3,L-U |
| 4 | 5-1/8'',10M X 4 outlets (4-1/16'',10M) | PR1,PSL3,L-U |
| 5 | 7-1/16'',10M X 4 outlets (3-1/16'',10M) | PR1,PSL3,L-U |
| 6 | 7-1/16'',10M X 4 outlets (4-1/16'',10M) | PR1,PSL3,L-U |
| 7 | 4-1/16'',15M X 4 outlets (3-1/16'',15M) | PR1,PSL3,L-U |
| 8 | 4-1/16'',15M X 4 outlets (4-1/16'',15M) | PR1,PSL3,L-U |
| 9 | 5-1/8'',15M X 4 outlets (3-1/16'',15M) | PR1,PSL3,L-U |
| 10 | 5-1/8'',15M X 4 outlets (4-1/16'',15M) | PR1,PSL3,L-U |
| 11 | 7-1/16'',15M X 4 outlets (3-1/16'',15M) | PR1,PSL3,L-U |
| 12 | 7-1/16'',15M X 4 outlets (4-1/16'',15M) | PR1,PSL3,L-U |
| Fracturing Head- | ||
| Item | Description | Specification |
| 1 | 4-1/16'',10M X 6 outlets (3-1/16'',10M) | PR1,PSL3,L-U |
| 2 | 4-1/16'',10M X 6 outlets (4-1/16'',10M) | PR1,PSL3,L-U |
| 3 | 5-1/8'',10M X 6 outlets (3-1/16'',10M) | PR1,PSL3,L-U |
| 4 | 5-1/8'',10M X 6 outlets (4-1/16'',10M) | PR1,PSL3,L-U |
| 5 | 7-1/16'',10M X 6 outlets (3-1/16'',10M) | PR1,PSL3,L-U |
| 6 | 7-1/16'',10M X 6 outlets (4-1/16'',10M) | PR1,PSL3,L-U |
| 7 | 4-1/16'',15M X 6 outlets (3-1/16'',15M) | PR1,PSL3,L-U |
| 8 | 4-1/16'',15M X 6 outlets (4-1/16'',15M) | PR1,PSL3,L-U |
| 9 | 5-1/8'',15M X 6 outlets (3-1/16'',15M) | PR1,PSL3,L-U |
| 10 | 5-1/8'',15M X 6 outlets (4-1/16'',15M) | PR1,PSL3,L-U |
| 11 | 7-1/16'',15M X 6 outlets (3-1/16'',15M) | PR1,PSL3,L-U |
| 12 | 7-1/16'',15M X 6 outlets (4-1/16'',15M) | PR1,PSL3,L-U |
BV inspection prior shipment
API 6A certificate
HOUSTON OTC exhibition
Factory overview
Machining and heat treatment shop
Forging Factory
QUALITY CONTROL
PRODUCTS MANUFACTURED BY JEFA
JEFA Supply follow API6A standard products with competitve price with superior quality and service
2 FC gate valves/WKM expanding valves/Demco mud valves/BSO gate valves/Hydraulic gate valve/ plug valves/H2 Chokes
JEFA machinery is a full service,APIcertified, precision machining and fabrication business that specializes in the design and manufacture wellhead equipment for all of your petroleum and natural gas extraction applications.In addition to providing superior quality and competitive rates on API 6A&16C products and other wellhead supplies, we can also supply you with OEM projects. We are firmly dedicated to providing the highest quality products and services for today's oilfield industry. →Head office in Shanghai ,2 plants in Yancheng, Jiangsu
→2014 sales over 200 million
→Over 200 employees
→Design and research capability
We are constantly striving to improve designs,streamline manufacturing processes, and reduce costs so that we can better serve our customers. Welcome to contact us for more details.
SHANGHAI JEFA MACHINERY CO.,LTD
Add :Room 513,Block A,No 581 Xiuchuan Road, Pudong, Shanghai, China 201200
Tell:+86 58901358 Fax:+86 21 58901369
skype: jefachina-emily.huang
1 How long can i get products?
A 1 week for stock products
B 6 ~7 weeks if no stock
2 Which trading terms do you offer?
We can do Ex-work, Fob Shanghai ,CIF or Door to Door
3 What is your MOQ?
We welcome trial order ,1 pc is acceptable to verify quality
4 Where is your factory?
JEFA's forging factory located in Huai'an Jiangsu
JEFA'S machining and heat-treatment factory located in Jianhu.Jiangsu
JEFA's Assembly factory located in Jianhu.Jiangsu
It takes 4 hours drive from Shanghai to factory.
