1) High resolution: 0.01dB;
Good accuracy:±0.2dB;
2) Insertion loss test in dB;
3) SM or MM applications;
4) FC/PC and 2.5mm universal connector;
5) 850/1300/1310/1490/1550/1625nm
Calibrated CW wavelengths;
6) T-OP100 is for telecom testing,
BPM101 is for CATV testing;
7) Energy save mode: about 10 minutes
no operation will cause the device
automatic power off (can be cancelled);
8) Reference value storage;
9) Full energy can support above 100
hours operation;
Main Characteristic
|
T-OP100E |
T-OP100H |
Display Range |
+10 ~ -70dBm |
+26 ~ -50dBm |
Accuracy * |
± 0.2dB |
|
Calibrated Wavelengths |
850nm / 1300nm / 1310nm / 1490nm / 1550nm / 1625nm |
|
Resolution |
0.01dB |
|
Connecting Adapter |
FC/PC & 2.5mm Universal |
|
Reference Value storage |
Yes |
|
Automatic Power Off |
No operation in 10 minutes (can be cancelled), Low battery energy |
|
Battery Charge |
Yes |
|
Battery Life |
Above 100 hours (1800mAH battery) |
|
Storage Temperature |
-20 -- +60 °C, < 90%RH |
|
Operating Temperature |
-10 -- +50 °C, < 90%RH |
|
Power Supply |
AA * 2 batteries or AC/DC power supply adapter |
|
Size |
160mm * 75mm * 32mm |
|
Weight |
About 180g |
|
* at 20±3°C, CW, with FC connector, -10dBm
* For 850nm/1300nm, the Min. Power measurement is -60dBm@BPM100, -40dBm@BPM101
Why choose us?
1. Professional: Specialized in manufacturing and selling optical fiber devices for more than 4 years.
2. Excellent quality: All our products have pasted the tests by SGS & CE.
3.Quick delivery: All our goods can be delivered within 3 working days.
4. Reasonable price: We provide the pretty cost-effective products.
5. We treat our workers and other suppliers as respectful partners
6. Caring after-sale services: Long warranty time, free technical instructions and
special training make you using our goods without any worries.
Packaging Details: |
carrying bag, packing box, user manual, calibration certificate |
Delivery Detail: |
1-3 working days after receiving the payment,
Shipped by DHL, UPS, FedEx,or the other ways based on customers' choices |
Contact Info:
Contact person: Tony Zu
Tel: 86-25-66061887 Fax: 86-25-84523090
Mob: 86-15298398621
SKYPE: tony.zu2813
Accessories
Standard |
Carrying bag |
1 |
User’s manual |
1 |
|
Calibration certification |
1 |
|
Optional |
AC/DC adapter |
1 |
