Help CenterSuperior Power Meter Tester Handheld Model Price
Related Products
-
Good Performance Power Meter Set China Supplier CompetitiveNegotiableMOQ: 1 Set -
Japanese Quality Power Meter Set China Supplier Competitive Price Good QualityUS$ 30 - 50MOQ: 1 Unit
-
Superior Optic Power Meter AOP100 Tester PriceNegotiableMOQ: 1 Set
-
High Quality Power Meter in Lowest Price Good QualityUS$ 200 - 300MOQ: 1 Unit
-
Superior Power Meter AOP100 Tester Cheap and Fine PriceUS$ 150 - 200MOQ: 1 Unit
1. Professional: Specialized in manufacturing and selling optical fiber devices for more than 4 years.
2. Excellent quality: All our products have pasted the tests by SGS & CE.
3.Quick delivery: All our goods can be delivered within 3 working days.
4. Reasonable price: We provide the pretty cost-effective products.
5. We treat our workers and other suppliers as respectful partners
6. Caring after-sale services: Long warranty time, free technical instructions and
special training make you using our goods without any worries.
Packaging Details: |
carrying bag, packing box, user manual, calibration certificate |
Delivery Detail: |
1-3 working days after receiving the payment,
Shipped by DHL, UPS, FedEx,or the other ways based on customers' choices |
Contact Info:
Contact person: Tony Zu
Tel: 86-25-66061887 Fax: 86-25-84523090
Mob: 86-15298398621
SKYPE: tony.zu2813
1) Wide measuremen range;
High resolution: 0.01dB;
Good accuracy:±0.2dB;
2) Insertion loss test in dB;
3) FC&2.5mm UPP;
4) 850/1300/1310/1490/1550/1625nm
calibrated wavelengths;
5) Data storage
6) Data transfer (optional)
7) 7X24 real-time test on PC; (optional)
8) Built in VFL (optional);
9) Energy save mode;
10) Reference value storage;
11) Full energy can support above 100
hours operation;
Model Options:
AOP100 X - Y - U
X: RANGE OF OPM |
Y: POWER OF VFL |
U |
|||
+10~ -70dBm |
+18~ -60dBm |
+26~ -50dBm |
1mW |
10mW |
data transfer and real time monitor with software on PC |
T |
M |
C |
V01 |
V10 |
|
For example:
AOP100T, AOP100C
AOP100T-V01, AOP100T-V10
AOP100T-U, AOP100T-V01-U
Main Characteristic
Accuracy * |
± 0.2 dB |
Calibrated Wavelengths |
850nm / 1300nm / 1310nm / 1490nm / 1550nm / 1625nm |
Display Resolving Power |
0.01dB |
Connecting Adaptor |
FC & 2.5mm UPP, (option: FC/SC/ST interchangeable adapter) |
Reference Value storage |
Yes |
Automatic Power Off |
No operation in 10 minutes (can be cancelled), Low battery energy |
Build in VFL (Optional) |
1mW or 10mW or customize |
Data Storage |
40 traces |
Battery Charge |
Yes |
Wave ID (Optional) |
Yes |
Data Transfer (Optional) |
Yes |
Real Time Monitor (Optional) |
10minutes to 360 days, interval: 0.5s, 2s, 15s, 60s, 180s, 600s |
Battery Life |
Above 100 hours |
Storage Temperature |
-20 -- +60 °C, < 90%RH |
Operating Temperature |
-10 -- +50 °C, < 90%RH |
Power Supply |
AA * 2 batteries or AC/DC power supply adapter |
Size |
170mm * 97mm * 38mm |
Weight |
About 380g |
* at 20±3°C, CW, with FC connector, -10dBm
For 850nm, the Min. Power measurement: -60dBm@EPM30T, -40dBm@EPM30C, -50dBm@EPM30M
Accessories
Standard |
Carrying bag |
1 |
User’s manual |
1 |
|
Calibration certification |
1 |
|
Optional |
FC/SC/ST interchangeable adapter |
1 |
FC male to LC female adapter |
1 |
|
Software and USB cable |
1 |
|
AC/DC adapter |
1 |
