Brand New China Optical Laser Source Set and Fusion Splicer

Name: Brand New China Optical Laser Source Set and Fusion Splicer
Brand: SKYCOM
SKU: 116047339
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

SKYCOM

Model Number:

T-OL10x

Nanjing Tianxingtong Electronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name SKYCOM

Model Number T-OL10x

1) T-OL102S: single wavelength

T-OL102M: two wavelengths

T-OL103S: three wavelengths

2) High stabilization;

3) 270, 1000, 2000 Hz Tone

4) LCD display & backlight;

5) Battery energy indication in LCD;

6) Battery charge indication in LCD;

7) Energy save mode: about 10 minutes

no operation will cause the device

automatic power off (can be cancelled);

8) Full energy can support above 16

hours operation;

Wavelength Option:

Example:

T-OL103S, it has 1310nm,1490nm,1550nm

T-OL102S, it has 1310nm,1550nm

Main Characteristic

	T-OL101-X	T-OL102x	T-OL103-X
	Single wavelength	Two wavelengths	Three wavelengths
Wavelength (nm)	850 / 1300 / 1310 / 1490 / 1550 / 1625
Stabilization*	±0.05dB / 1 hour; ±0.1dB / 8 hours
Output Power	> - 6 dBm @ 1310nm/1490nm/1550nm/1625nm
	> -10 dBm @ 850nm/1300nm
Modulation	270Hz, 1KHz, 2KHz
Connector	FC/PC (or SC or ST or 2.5mm universal)
Auto Power Off	No operation in 10 minutes (can be cancelled), Low battery energy
Battery Charge	Yes
Operate Time	Above 16 hours (1800mAH battery)
Storage Temperature	-20 -- +60 °C, < 90%RH
Operating Temperature	-10 -- +50 °C, < 90%RH
Power Supply	AA * 2 batteries or AC/DC power supply adapter
Size	160mm * 75mm * 32mm
Weight	About 180g
