1x8 Slot Box Fiber PLC Splitter
US$ 5 - 8.5
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
tianxing
Model Number:
1x8 insertion type
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cheapest Price 2.0mm 1.5M Pigtail Fanout SC PC 1x4 Optical SplitterUS$ 3 - 6MOQ: 500 Pieces -
SC 32 Port Passive Optical Splitter for FTTHUS$ 23 - 28MOQ: 500 Pieces
-
Rock-bottom Price Stainless Steel Tube SC UPC 1x4 PLC SplitterUS$ 3 - 6.5MOQ: 500 Pieces
-
Splitter 1x8 0.9mm 1,5Mts SM SC APC Plc ConectorizadoUS$ 2.5 - 5.5MOQ: 500 Pieces
-
Splitter PLC Conectorizado 1x4 0.9mm Mini Module SC APC 1,5mtsUS$ 2.5 - 7MOQ: 500 Pieces
Place of Origin
Jiangsu, China
Brand Name
tianxing
Model Number
1x8 insertion type
1x8 slot box fiber PLC splitter
1. Feature
1).Low Insertion loss
2).Low PDL
3).Compact Design
4).Good channel-to-channel uniformity
5).Wide Operating Wavelength: 1260-1650nm
6).Wide Operating Temperature: -40°C - 85°C
7).High Reliability and Stability
2. Application
1).FTTX Systems
2).PON Networks
3).CATV Links
4).Optical Signal Distribution
3. Specification
Product Description
technical specification:
| Fiber optic PLC splitter technical specifications | |||||||
| wavelength(nm) | 1260-1650 | ||||||
parameters |
1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 1x128 |
insertion loss (dB) |
≤4.2 | ≤7.4 | ≤10.7 | ≤13.9 | ≤17.2 | ≤21.5 | ≤24 |
| PDL (dB) | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.4 | ≤0.5 |
| Uniformity (dB) | ≤0.6 | ≤0.8 | ≤0.8 | ≤1.0 | ≤1.5 | ≤2.0 | ≤2.0 |
| return loss (dB) | ≥50 | ||||||
| directivity (dB) | ≥55 | ||||||
| temperature range (°C) | -40~+75 | ||||||
| storage temperature (°C) | -40~+85 | ||||||
| NOTE: The above parameter is for splitter with connector, if w/o connector, insertion loss will reduce by 0.2dB. | |||||||
Encapsulation Size for PLC Splitter Slot Type
| Item | Type of Connector | Length*Width*Height (mm) |
| 1x2 | SC/LC | 130*100*25 |
| 1x4 | SC/LC | 130*100*25 |
| 1x8 | SC/LC | 130*100*25 |
| 1x16 | SC/LC | 130*100*50 |
| 1x32 | SC | 130*100*102 |
| 1x32 | SC | 267*100*50 |
| 1x32 | LC | 130*100*50 |
| 1x64 | LC | 130*180*102 |
4. Product show
5. Factory bulding
Company Information
6. shipment
Packaging & Shipping
7. Contact us
Sales: Eve Yao
Skype: trade. eve
web:
Tel: 86 511 83565358
Fax: 86 511 83565357
We sincerely welcome all interested buyers to visit our factory and contact us directly for further information, we will reply you as soon as possible!
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2012
Factory Size
Below 1,000 square meters
Total Employees
101 - 200 People
