Help Center1KV-10KV Insulation Piercing Ground Connector, JJCF10 Insulation Cable Clamp
Related Products
-
1KV Insulation Piercing Connector, Waterproof Electrical Connector, JJCUS$ 1 - 10MOQ: 10 Pieces -
Low Voltage Insulation Piercing Connector, 1KV Pin ConnectorUS$ 1 - 10MOQ: 10 Pieces
-
Insulating Piercing Connector IPC Cable Clamp, Clamp ConnectorUS$ 1 - 10MOQ: 10 Pieces
-
Series Insulation Piercing Connector, Connector Electrical , TTDUS$ 1 - 10MOQ: 10 Pieces
-
Insulating Piercing Connector IPC Cable Clamp, Clamp Connector Wire ConnectorUS$ 2 - 10MOQ: 10 Pieces
1) The Insulation Piercing Ground Connector installing and fixing main cable in traditional way.
2)Stripping outer insulator of main cable for 0.6m (don’t destroy insulation layer for phase).
3)Choosing branch cable (not more than 3m) whose distance is the same as electric meter box, and strip insulator at two terminals.
4)Installing the separator vertically by turns ( the sepatator distance is more than 10cm).
| Type | Equivalent type |
Applicable voltage (KV) | Applicable lead (mm2) |
Main dimension | Nominal current (A) |
Bolt number |
piercing depth (mm) |
||
| A | B | H | |||||||
| KNF10-185/95 | JJCF10-2 | 10KV & 1KV | 95-185 | 152 | 140 | 112.5 | 476 | 2 | 4.5-6 |
- 1. Professional Manufacturer
- 2. Standards: ANSI, IEC, BS, DIN
- 3. A wide range of low and high voltage electrical products:
Fuse Cutout |
Lightning Arrester |
Composite Insulator |
Glass Insulator |
Porcelain Insulator |
Insulation Piercing Connector |
Fuses |
Disconnector Switch |
Circuit Breaker |
Ring Main Unit |
Insulated Sheath |
Capacitor |
4. Factory Direct Price
5. Enough ability to meet buyers fresh designed items.
1. Payment : T/T or Irrevocable L/C at sight
2. Delivery time and method: Usually within 30 days
3. Port of loading: NINGBO, SHANGHAI, FUZHOU (CHINA)
4. MOQ: 10PCS
5. Package: Standard export packing or as per your requirement.
OEM/ODM can be acceptable by us. We will make a mould as per your sample.
If you discovers defects in workmanship and /or material and so notifies us promptly in writing. we shall with all reasonable speed remedy such defects of non-conformance to the specifications at our expense by replacement at the option of you.
