Place of Origin Guangdong, China
Brand Name HI-KEY,KEY-TEK
Model Number K-TEK-A120KP-BL
Application Other, computer keyboard
Keypad Button Material Other, metal

  4x4 usb vandal proof IP65 backlit access control keypad



DESCRIPTION:



Backlight/Illuminated LED (optional) inside on the PCB (Red, Green, White, Blue)16 keys compact format vandal-proof IP65 stainless steel access control  keypad with carbon-on-gold key switch technology for fast and accurate data input,with top panel mounting solution.



DIMENSIONS: 120.0mm x 98.0mm (Front Panel)



MAIN FEATURE

  • Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.
  • key-tops are sunk laser-etched in legends and characters via using high quality ink for easy readability, long life to prevent lettering rub-off.
  • With firm tactile key feel, full long carbon-on-gold key switches, with unique double over-travel protection.
  • Waterproof/dirt-proof execution according to degree of protection IP65, waterproof and dirt proof .
  • Easily mounting into enclosure or panel, and is provided with PS/2, or USB, RS232, connection output cables that plug directly into the host computer for normal keypad operations.
  • OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/Win7, Linux, Unix, Mac OSX

COMMUNICATION PARAMETER


  • USB, PS2 or RS232 are all available.
  • 16 actuator on the keypad: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, Exit, PgUp, PgDn, Enter, Clear, 4 x 4 scanning code. Any keys can be re-defined per customers' requirements.
  • 8 functional keys: F5, F10, F11, F12 and up/down/right/left arrows (optional)
MECHANICAL DATA
  • Switching material: Carbon-on-Gold.
  • Actuation Force: 0.6 N+/-0.1N for key 14.0mm x 14.0mm (pressure point), 1.2 N+/-0.1N for key 14.0mm x 28.0mm (pressure point)
  • Key Travel: 2.0mm.
  • Lettering: laser engraving, or raised letters.
  • Front panel: brushed stainless steel.
  • Actuator/keys materials: stainless steel.
  • G.W.: 1.0KGs.
  • Dimensions: 120.0mm x 98.0mm (top panel)

ELECTRICAL DATA


  • Communication interface: PS2, USB or RS232 are all available.
  • EMC:EN55022(B).
  •  Electrical lifetime: > 5 years.
  •  Power Consumption: Under 300mW for operation, under 200mW for non-operation.
  • Power supply voltage: 5V DC.

ENVIRONMENTAL ADAPTABILITY

  • Operating temperature:-20oC to +60oC
  • Storage temperature: -30oC to +70oC
  • Operating RH: 30-90%
  • Atmospheric pressure: 60-106Kpa.
  • Saline mist: 96 hours, IEC 60512-6
  • Damp heat test at + 40oC: 21 days, IEC 60512-6
  • Dry heat test at + 85oC: 10 days, IEC 60512-6

RELIABILITY

  • RoHS Compliant, CE and FCC
  • Protection Level: IP65(front panel)
  • Vandal resistant IK10
  • Key Lifespan >10 million actuations
  • MTBF >50000H
  • MTTR <30min
16 keys IP65 dynamic waterproof keypad with backlight



16 keys IP65 dynamic waterproof keypad with backlight

16 keys IP65 dynamic waterproof keypad with backlight16 keys IP65 dynamic waterproof keypad with backlight
