Home > Computer Products > Keyboard > Mechanical Keyboard > Patented DWP Technology Deep Waterproof Programmable Keypads

Patented DWP Technology Deep Waterproof Programmable Keypads

Name: Patented DWP Technology Deep Waterproof Programmable Keypads
Brand: K-TEK
SKU: 116015367
Availability: InStock

Key Technology (China) Limited

Patented DWP Technology Deep Waterproof Programmable Keypads thumbnail-1

Patented DWP Technology Deep Waterproof Programmable Keypads thumbnail-2

Patented DWP Technology Deep Waterproof Programmable Keypads photo-1

Patented DWP Technology Deep Waterproof Programmable Keypads photo-2

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

K-TEK

Model Number:

K-TEK-A100KP-RP-DWP

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen HongKong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name K-TEK

Model Number K-TEK-A100KP-RP-DWP

Application Other, bank/kiosk

Keypad Button Material Metal

MODEL NO.: K-TEK-A100KP-RP-DWP

DESCRIPTION: 16 keys compact format IP67 dynamic water proof and vandal proof stainless steel industrial keypad with fully sealed & ruggedized industrial PCB connected to industrial electronics controller shielded & protected by stainless steel housing, carbon-on-gold key switch technology with long stroke (2.0mm) with extremely good tactile feeling for fast and accurate data input without any noise, with mounting holes on rear stainless steel plate for rear panel mounting. Which is good for outdoor application with direct rain and very harsh environments with humidity, much dynamic water, oil, dirt, salt mist etc, no rust risk and anti-salt spray corrosion.

DIMENSIONS: 100.0mm x 90.0mm (front panel)

APPLICATION

This Keypad is mainly targeted for use for unsupervised or semi-supervised positions of varied access applications, internet terminals and information kiosks at universities, shopping malls, hotels, banks, airports, railway-stations and other public areas, ticket vending machines, gas stations, cash machines (ATMs/CDM), Internet public phones etc.

MAIN FEATURE

Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design, functionality, longevity and high protection level.
Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic conditions, water proof/dirt proof, operation under hostile environments.
Waterproof execution according to IP67 protection from top panel, rear stainless steel plate with mounting holes and sealing gasket for easy tightly mounting to panel.
An excellent tactile feel with full-long travel switches and allow users to achieve fast and accurate data input without any noise. With firm tactile perception for comfortable operation
key-tops are laser-etched in legends and characters for easy readability, long life to prevent lettering rub-off.
Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key covers.
Ease of customizing with multiple languages, to accommodate foreign or custom variants.
- Complete electronic modules including controller in close consultation with our customers are available.

ELECTRICAL DATA

Supply Voltage: +5V DC +/-5%
Current Rating: appr. 20mA
EMC Standard: It is compliance with the council IEC 61000-4-2:2008;IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004
EMI: EN 55022: 2010
EMS: EN 55024: 2010
Lifespan > 5 years
Switch Contact Material: Carbon-on-Gold key switch technology PCB.
Interface: PS2, USB, RS232, RS485 available
OS: All windows, Linux, Unix, Mac OSX

COMMUNICATION PARAMETER

PS2/USB:

Standard PS2/USB keyboard interface.
16 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, Cancel, Clear, Enter, backup key 3, 4 x 4 scanning code

RS232:

Standard RS232 serial interface.
Communication velocity: 9600bps.
Data format: N, 8, 1.
16 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, Cancel, Clear, Enter, backup key 3, 4 x 4 scanning code

MECHANICAL DATA

Front plate: Super quality SUS304 brushed stainless steel
Back plate:Super quality SUS304 stainless steel
Actuator/Key: 16 keys, super quality SUS304 brushed stainless steel
Key top style: protuberant rectangular keys, with laser engraved and etched legends and raised dots available.
Key size: 14.0mm x 14.0mm for normal key, 14.0mm x 28.0mm for function keys
Switching material: Carbon-on-Gold.
Actuation Force: 0.60N +/-0.10N (pressure point), 1.20 N+/-0.1N for key 14.0mm x 28.0mm (pressure point)
Key Travel: 2.0mm.
Key life: 10 million of operation
Dimensions: 100.0mm x 90.0mm.
G.W. 0.66kg.
