5 Keys Industrial Metal Bank Function Keypad
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Key-Tek
Model Number:
K-TEK-B110FK
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen Zhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Function Keypad for More Use in Pharmacy Safe BoxNegotiableMOQ: 5000 Pieces -
Function Keypad in Super Quality Stainless SteelNegotiableMOQ: 1 Set
-
Latest Design Black Titanium 20 Keys Function KeypadNegotiableMOQ: 1 Piece
-
5 Keys Vandal Proof IP65 Function KeypadNegotiableMOQ: 1 Set
-
4 Keys Vandal Proof IP65 Function KeypadNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Key-Tek
Model Number
K-TEK-B110FK
Application
Other, industrial application
Keypad Button Material
Metal
Specifications
1.4 keys vandal proof function keypad2.super quality stainless steel
3.gold-on-gold key switch technology.
Dimension:110.0mm x 24.0mm
Description:4 Keys Vandal proof IP65 Stainless Steel dot matrix function keypad with metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm, without electronics controller, top panel mounting.
MAIN FEATURE:
- Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.
- key-tops are sunk laser-etched in legends and characters via using high quality ink for easy readability, long life to prevent lettering rub-off. Or protrusive engraving available
- With firm tactile key feel, short travel gold-on-gold key switches, with unique double over-travel protection.
- Waterproof/dirt-proof execution according to degree of protection IP65, waterproof and dirt proof encapsulation with unique membrane.
- Easily mounting into enclosure or panel.
MECHANICAL DATA:
- Switching Material: Gold-on-Gold
- Actuation Force: 2.0N+/-0.1N (pressure point)
- Key Travel: 0.45mm
- Lettering: laser engraving, or raised letters.
- Front Panel: brushed stainless steel
- Actuator/Keys Materials: stainless steel
- Dimensions: 110.0mm x 24.0mm
- G.W. 0.20KGs
ELECTRICAL DATA:
- Power Supply Voltage: 5.0V DC.
- Power Consumption: Under 150.0mW for operation, under 50.0mW for non-operation
- Electrical Lifetime: > 5 years
- EMC:EN55022(B)
ENVIRONMENTAL ADAPTABILITY:
- Operating Temperature:-20°C to +60°C
- Storage Temperature:-30 °C to +70°C
- Operating RH: 30 ~ 90%
- Atmospheric Pressure: 60 ~ 106Kpa.
RELIABILITY:
- RoHS Compliant, CE and FCC
- Protection Level: IP65(front panel)
- Vandal resistant IK10
- Key Lifespan >5 million actuations
- MTBF >50000h
- MTTR <30min
