Dustproof Desktop Ip68 Rubber Keyboard With Numeric Keypad for Medical

Dustproof Desktop Ip68 Rubber Keyboard With Numeric Keypad for Medical photo-1
Dustproof Desktop Ip68 Rubber Keyboard With Numeric Keypad for Medical photo-2
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
IKB-MKB
Model Number:
K-TEK-M399KP-FN-DT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name IKB-MKB
Model Number K-TEK-M399KP-FN-DT
Application Other, IP68 keyboard
Keypad Button Material Metal

Dustproof desktop ip68  rubber keyboard with numeric keypad for medical



K-TEK-M399KP-FN-DT



Quick Detail:

1. IP68 dynamic rated & ruggedized industrial silicone rubber Hygienic keyboard

2. Integrated numeric keypad with function keys.

3. Backlight optional



Description:

1. 106 keys IP68 dynamic rated & ruggedized industrial silicone rubber Hygienic keyboard with industrial PCB included

2. integrated numeric keypad, function keys

3.industrial PCB with carbon-on-gold key switch technology with long stroke (1.50mm) with extremely good tactile feeling for

fast and accurate data input without any noise

4.with durable coating & antimicrobial keyboard surface withstand to most chemicals and liquids under harsh environment

5. Clean key for easy cleaning, movable stand alone desk top version with robust polycarbonate case

6. adjustable industrial backlight optional, military level optional.



Special Features:

1. keyboard with NVIS-compliant red adjustable backlighting optional, while NVIS backlighting makes this keyboard ideal for

aviation or vehicle applications where night vision goggles are necessary.

2. Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionality

3. The keyboard lacks the crevices found between the keys of a regular keyboard, which is protected against dust, dirt,

grease and corrosive liquids to NEMA 4X, which means it can withstand directed hose water, disinfectants, environmental

contaminants and heavy industrial use.

4. Special durable-coating for excellent mechanical and chemical resistance

5. Clean key

----Prevents data from being sent while the keyboard is wiped down, allowing user to clean at any interval with minimal

downtime

---- User is notified of ‘lock down mode’ by brightly lit CLEAN KEY

6. With firm tactile key feel, key travel 1.5mm key travel.

7. Integrated numeric keypad and function keys

8. Ease of customizing with multiple languages, to accommodate foreign or custom variants.

9. PS/2, USB connection cables that plug directly into computer like keyboard operations.

10. Enclosure: industrial silicone, Robust ABS Polycarbonate Case



Applications:

This keyboard is ideal for use in environments ranging from manufacturing to material handling to medical settings. Its

numeric pad allows for easy data entry.

A: MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;

B: MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc

C: MILITARY: Army, Navy, Air force

D: INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing

environments, warehouses

E: OTHER INDUSTRIES



Specification

MECHANICAL DATA

Key

106 keys

Key top style

Protuberant rectangular keys with tactile feeling.

Key Size

12.0mm X 13.0mm for normal keys,

22.5mm x 13.0mm for enter key

82.0mm x 12.5mm for space bar key.

Key travel

1.5mm

Switch life

more than 10 million of operations

G.W.

1.60KGs

Dimensions:

399.0mm x 150.0mm x 20.0mm (L x W x H)



ELECTRICAL DATA

Supply Voltage

+5V DC +/-5%

Current Rating

20mA (non-backlight), 140mA (with backlight on)



EMC Standard:

It is compliance with the council IEC 61000-4-2:2008;IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004

EMI:

EN 50081-1

Immunity:

EN 50082-1

Lifespan

> 3 years

Switch Contact Material:

Carbon-on-Gold key switch technology with gold PCB.

Interface:

PS2, USB available.

OS:

All windows, Linux, Unix, Mac OSX



ENVIRONMENTAL ADAPTABILITY

Operating temperature

-20oC to +60oC(industrial level);-40oC to +85oC(military level)

Storage temperature

-30oC to +70oC(industrial level);-55oC to +150oC(military level)

Humidity

100%

Atmospheric pressure

60-106Kpa

Shock

3x11 ms pulses of 50g on each of 3 axes

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz, FREQUENCY RANGE: 20Hz - 2kHz, DURATION OF TEST PER AXIS: 3 hours Flammability

Printed Circuit Board

94 VOSILICONE OVERLAY: 94 HBINTERFACE CABLE: 94 V



RELIABILITY

Certification

RoHS Compliant, CE and FCC, IP68,ESD

Protection Level

IP68;NEMA 6P

Key Lifespan

>10 million actuations

MTBF

>50000H

MTTR

<30min





Dustproof desktop ip68 rubber keyboard with numeric keypad for medicalDustproof desktop ip68 rubber keyboard with numeric keypad for medical
