Help Center38mm Stainless Steel Ruggedized Metal Trackballs
Related Products
-
USB PS/2 Stainless Steel Waterproof TrackballNegotiableMOQ: 1 Piece -
38mm Industrial Usb Trackball in Factory PriceNegotiableMOQ: 1 Piece
-
38mm Mechanical Industrial Trackball(panel Mounted)NegotiableMOQ: 1 Piece
-
38mm Stainless Steal Trackball Wired USB PS/2 InterfaceNegotiableMOQ: 1 Piece
-
38mm Mounted Trackball Stainless Steel in Factory PriceNegotiableMOQ: 1 Piece
Model NO:K-TEK-B107-38-LTB
Dimension:107.0mm x 120.0mm (top panel)
Description:IP65 dynamic rated vandal proof stainless steel laser trackball with IP65 dynamic sealed & ruggedized stainless mouse buttons and IP68 dynamic rated washable 38.0mm stainless steel laser trackball module with +1200 DPI resolutions for fast and accurate fixing cursor position with extreme smooth operation without any noise, optical trackball module protected and shielded by stainless steel housing, 3 sealed stainless steel mouse buttons designed for right & left clicking and scrolling up and down with ball rolling, stainless steel top plate with threaded bolts for top panel mounting solution.
MAIN FEATURE
Emulates most popular mice - uses existing mouse driver and mouse software Interfaces for most workstations and computers.
All Metal Mechanicals provide for rugged, smooth, long lasting and no noisy operation.
Laser Encoders provide high resolution more than 1200DPI, fast and reliable positioning data.
Available 38mm diameter Stainless steel for smooth, quick and durable operation and precise cursor positioning.
Rate Sensitive Dynamic Resolution provides for accelerated movement of the cursor when the ball is moved fast, while retaining one-pixel positioning accuracy when the ball is moved slowly.
can be mounted horizontally, and vertically.
no metal bearings inside, operation is very smooth, and easy without any noise.
TECHNICAL SPECIFICATION
ITEM |
SPECIFICATION |
|
Mechanical |
Key |
2 or 3 keys, quality brushed stainless steel |
Key top style |
sealed round stainless steel buttons with tactile feeling |
|
Front Plate |
Quality brushed stainless steel |
|
Key Travel |
1.00 mm |
|
Ball diameter |
38.1mm/1.50" (19mm, 25mm, 36mm 40mm also available) |
|
Key switch lifespan |
more than 10 Mio actuations |
|
Track ball lifespan |
> 10 Mio revolutions |
|
Back Metal Cover |
Rear side integrated electronics protected by a metal cover |
|
Actuation Force |
1.0N to 3.0 |
|
Mounting Rack |
top stainless steel plate with mounting screw bolts |
|
Dimension |
Dimensions with 38mm track ball, Front plate (W x H): 107.0mm x 120.0mm |
|
Interface |
PS2, USB are available, Y type cable with ports of PS2 and USB |
|
Electrical |
Power supply |
5V DC+ 10%, mouse interface |
Protection level |
IP65 dynamic (front panel), NEMA3, IK10 |
|
EMC Standard |
EN55022(B) |
|
Power consuming |
≤1.00W(dynamic) |
|
≤0.2W(static) | ||
Contact Material |
sealed stainless steel buttons |
|
Environmental |
Operating temperature |
-20ºC~+ 60º C |
Storage temperature |
- 30ºC~+ 70ºC |
|
Operating RH |
30~90% |
|
Atmospheric pressure |
60~106Kpa. |
|
Reliable |
Certificates |
RoHS compliant, CE and FCC certified. ESD |
MTBF |
>50000H |
|
MTTR |
< 30min |
|
OS |
OS is under All windows, Linux, Unix, Mac OS9 / OSX |
|
Packing Details |
Each unit to a suitable brown box, suitable brown boxes to a standard export carton. |
|
All of our products have CE, ROHS, FCC, IP65, IP68 and Patents!
KEY-TEK guarantee our products and workmanship up to a full year!
