Dimension:100.0mm x 91.4mm (Front Panel)
Description:16 keys Compact Format Vandal proof IP65 Stainless Steel PINPAD with Encryption Module Supporting DES/TDES, metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm, rear panel mounting solutions.
APPLICATION:
This encryption PINPAD is mainly targeted for use for unsupervised or semi-supervised positions of varied bank access applications, Bank kiosks, ATM, CDMs etc.
MAIN FEATURE:
Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.
Internet friendly key layout, key-tops are sunk laser-etched in legends and characters via using high quality ink for easy readability, long life to prevent lettering rub-off. Or protrusive engraving available.
The PINPAD in 4 x 4 matrix with Enter, Cancel, Correction, etc. compliance with ISO standard
16 bytes keys (16 master keys x 4 working keys), it can be self destructive with back-up battery to achieve this function
The PINPAD can be used as a normal keypad for numeric entry
The ATM can instruct PINPAD to exit key entry/supervisory mode
2 functional keypads are optional.
COMMUNICATION PARAMETER:
Standard RS232 serial interface
Communication velocity: 19200, 9600, 4800, 2400, 1200bps
Data format: N, 8, 1
16 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, correct, enter, cancel, backup key 3 defined for ABC.The key 2, 3…9 can support the related English letters under suitable systems.
Data encryption and decryption (DES/TDES), PINBLOCK, MAC Algorithm.
Encryption rate: < 1 second
MECHANICAL DATA:
Actuation Force: 3.0N (pressure point)
Key Stroke: 0.45mm
Front panel: brushed stainless steel
Actuator/keys materials: stainless steel
Mechanical Key lifespan: 5 Mio actuations
Lettering: laser engraving or raised letter
Dimensions: 100.0mm x 91.4mm x 33.0mm (L x W x H)
NW: 1.0KGs
ELECTRICAL DATA:
Switching Material: Metal dome PCB with Gold-on-Gold Key Switch Technology.
Power Supply Voltage:+5V DC
Power consumption:
Under 1W for operating condition, 200mA for non-operating condition
EMC: EN55022(B)
Communication Interface: RS232 or USB available.
Enter PIN: 10 numerical keys and 6 function keys.
ENVIRONMENTAL ADAPTABILITY:
Operating temperature: -20°C to +60°C
Storage temperature:-30°C to +70°C
Operating RH: 30--90%
Atmospheric pressure: 60-106Kpa.
Keypad is watertight while being mounted correctly on ATM
RELIABILITY:
RoHS Compliant, CE and FCC
Protection Level: IP65(front panel)
Vandal resistant IK10
Sensitive data can be well saved while sudden power off.
Sensitive data and program can be erased when being tampered.
Key Lifespan > 5 million actuations
MTBF >50000H
MTTR <30min
