Fire Control Mitsubishi Pressure Switch 708

Specifications

fire control mitsubishi pressure switch

Advantages:
fessional skill
2.Specific products
3.Tailored cost-effective production for our customers

Technical Parameter:

1, Switching type : SPST NC or SPST NO or SPDT NC+NO  or DPST  or DPDT(Selectable),

    Switch frequency & Response time: 60 Cycle /min, ≤100ms.

2, Pressure fitting: R 1/2"-14 BSPT male .

3, Electrical connection: a variety of user-selectable.

4, Voltage: 5-110VDC, 5-250VAC;

    Resistance load : 0.1-3A,  Inductive load : 0.1-1.5A.

5, Fluid media: water &  gas & air & fire extinguishing agent,etc.

6, Work Life: ≥100,000 Cycle.

7, Protection  class : IP65.

8, Ambient temperature: -40°C~125°C(Selectable), Medium temperature: -40°C~150°C(Selectable).

9, Model: a variety of user-selectable.

10,Working pressure: Vacuum -14.5PSI to +3000PSI (Selectable).

After-sales service:

              We promise to carry out the following after-sales service:

       Warranty: The warranty period is 12 months starting from the shipping date.

 The rate of Production Quality Problem is lower to 100PPM, replace the bad for free.

Certificate:

Productio Photo:

Dimension Drawing:
