Help CenterLow Pressure Switch Air Compressor
Related Products
Specifications
low pressure switch air compressorSuitable for Air compressor
stable performance
selectable switch model
compact size
low pressure switch air compressor
Technical Parameter:
1, Switching type : SPST NC or SPST NO (Selectable),
Switch frequency & Response time: 60 Cycle /min, ≤100ms.
2, Pressure fitting: 1/4"-18NPT Thread ( Male ).
3, Electrical connection: UL 1015 18AWG, Lead wire .
4, Voltage: 5VDC to 110VDC, 5VAC to 250VAC;
Resistance load : 0.1A to 6A, Inductive load : 0.1A to 3A.
5, Fluid media: R22, R134a, R407c, R410a, etc.
6, Work Life: ≥100,000 Cycle.
7, Protection class : IP65.
8, Ambient temperature: -30°C~55°C, Medium temperature: -40°C~80°C.
9, Model: (Read table 1).
10,Working pressure: 10 to +800PSI (Selectable, Read table 2).
After-sales service:
We promise to carry out the following after-sales service:
Warranty: The warranty period is 12 months starting from the shipping date.
The rate of Production Quality Problem is lower to 100PPM, replace the bad for free
Certificate:
Production Photo:
Dimension Drawing:
