Stainless Steel Welding Electrode

Stainless Steel Welding Electrode thumbnail-1
Stainless Steel Welding Electrode photo-1
US$ 650 - 950 MOQ: 20 Tons
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Paladin, Horacle
Model Number:
AWS E6011,6013,7013
Contact Supplier Request Quote Chat Now
Hebei Euroasia Industry Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name Paladin, Horacle
Model Number AWS E6011,6013,7013
Material Stainless Steel
Length 300mm, 350mm, 400mm
Operating Current 50~240A
Welding Current 50~240A
Diameter 2.0mm,2.5mm,3.2mm,4.0mm,5.0mm
Application Mild Carbon Steel Structure, General Purpose

Specifications

Stainless Steel welding electrode
Qualified Mild Steel Welding Electrode
Swedish Technology
E6011,6013,7013

Stainless Steel welding electrode





Type GB Code AWS Code JIS Code Application
J421 E4313 E6013 D4313 Suitable for welding low carbon steel structure,especially for intermittent welding for small and thin plates and cosmetic welding which requests a neat welding surface.
J421X E4313 E6013 D4313 Suitable for welding low carbon steel structure and low carbon galvanized plate, ,especially applicable for vertical-down welding and intermittent welding.
J422 E4303 - D4303 Suitable for welding important low carbon steel structurers and structures fabricated by low tensile strength low alloy steel, such as Q235 steel, 09Mn2 steel etc.
J424 E4320 E6020 - Suitable for welding low carbon steel, such as heavy machinery,construction machinery etc.
J424Fe16 E4327 E6027 D4327 Suitable for welding important carbon steel structures.
J425 E4311 E6011 D4311 Suitable for butt,fillet and lap welding for thin plates structures, such as smoke pipes,wind pipes,oil tanks of transformer, outside cover of vehicles, etc.
J425G E4310 E6010 - Suitable for welding root passes,hot passes,filler and cover passes as well as for capping of general pipes and similar structures.
J426 E4316 E6016 ISO2560-B-E4316A - Suitable for welding important low carbon steel and   low alloy steel, such as Q235 steel, 09Mn2 steel etc.
J427 E4315 E6015 ISO2560-B-E4315A - Suitable for welding important low carbon steel and   low alloy steel.
J501Fe E5014 E7014 - Suitable for welding important carbon steel and   low alloy steel, such as ships,vehicles and machinery structures fabricated by 16Mn steel, etc.
J502 E5003 ISO2560-B-E4093-1A D5003 Mainly used for welding low alloy steel structures fabricated by Q345 steel.
J505 E5011 E7011 - Suitable for welding carbon steel and low alloy steel.
J505G E5010 E7010-G - Suitable for welding carbon steel and low alloy steel.
J506 E5016 E7016 D5016 Medium carbon steels and important low-alloy steels structures like 16Mn etc. for ship building
J507 E5015 E7015 D5015 Medium carbon steels and some low-alloy steels structures like 9Mn2V,16Mn steel etc,parts of ships fabricated by A,B,D,E grade
J507X E5015 E7015 - For welding important carbon steel and low tensile strength and low alloy steel pipes
J507Fe16 E5028 E7028 D5026 For but,cap,fillet,flat fillet welding and fillet welding in the downward position for thick and large structures of low alloy steel
J508 E5018 E7018 - For medium carbon steel and low alloy steel, such as 16Mn steel, parts of ships fabricated by A, B, D, E grade as well as parts of boilers, pressure vessels and pipes







Reference Current (AC, DC)

Diameter(mm)

φ2.0

φ2.5

φ3.2

φ4.0

φ5.0

Welding Current (A)

40~70

50~90

90~130

130~210

170~230

Chemical Composition of Deposited Metal (%)

Chemical Composition

C

Mn

Si

S

P

Guaranteed Value

≤0.12

0.3~0.6

≤0.35

≤0.035

≤0.040

Mechanical Properties of Deposited Metal

Test

Rm(MPa)

ReL(Mpa)

A(%)

KV2(J)

KV2(J)

Guaranteed Value

≥420

≥330

≥17

-(normal temperature)

-(0°C)

General Properties

460~540

≥340

18~26

50~80

≥47

X-ray Radiographic Inspection: 2 Degree

Stainless Steel welding electrodeStainless Steel welding electrodeStainless Steel welding electrode



Stainless Steel welding electrodeStainless Steel welding electrodeStainless Steel welding electrodeStainless Steel welding electrode
