Diameter 1.2MM Quality Welding Wire ER70S-6

Diameter 1.2MM Quality Welding Wire ER70S-6 thumbnail-1
Diameter 1.2MM Quality Welding Wire ER70S-6 photo-1
US$ 1,020 - 1,150 MOQ: 5 Tons
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
PALADIN,HORACLE,TIG,MAG
Model Number:
ER50-6,ER70S-6,SG2,YGT50,
Contact Supplier Request Quote Chat Now
Hebei Euroasia Industry Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG TIANJIN ANY CHINA PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name PALADIN,HORACLE,TIG,MAG
Model Number ER50-6,ER70S-6,SG2,YGT50,
Material CO2
Diameter 0.8,1.0,1.2,1.6mm, 0.8mm,1.0mm,1.2mm,1.6mm
Melting Point meeting standard
Weight 5kgs,15kgs,20kgs per spool
Application carbon steel,below 500Mpa alloy steel
Flux Content standard

Specifications

Diameter 1.2MM quality welding wire ER70S-6
Stable welding arc,low spatters
Excellent welding seam
For all welding position,q

Diameter 1.2MM quality welding wire ER70S-6

Welding wire have depositing speed and high efficiency, stable arc, little splash, good welding seam.
CO2 welding wire AWS A5.18 ER70s-6 factory
AWS ER70s-6; GB ER50-6; DIN SG2
0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.6mm
5kg, 15kg, 20kg
GB/T ER50-6 DIN SG2 JIS YGW12
AWS ER70S-6 BS A18 EN G3Si1
This ER70s-6 CO2 welding wire has excellent mechanical performance such as depositing speed and high efficiency, stable arc, little splash, good welding seam. This series of welding wires are suitable for the low carbon steel and low alloy structure, vehicle, bridge, container, construction machinery, boilers and construction etc.
- Diameter: 0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.6mm
-- Weight of spool: 5kg, 15kg and 20kg.


Introduction: Strong resistance to surface scales and oil stains on the base metal. It has low blowhole sensitivity.


Uses: 1. Used for welding all kinds of 500MPa structural steel parts.
2.Used for welding all kinds of 500MPa plates and pipes.


Chemical Composition of Welding Wire(%)
C
Mn
Si
S
P
Cu
0.06~0.15
1.4~1.85
0.8~1.15
≤0.035
≤0.025
≤0.50

Examples of Chemical Composition of Deposited Metal (%)
C
Mn
Si
S
P
Cu
0.07
1.27
0.76
0.014
0.015
0.15

Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
ReL/Rp0.2(Mpa)
A(%)
KV2(J)
Guarantee Value
≥500
≥420
≥22
≥27(-30°C)
General Result
558
472
27
98

Reference Current(DC+)
Wire Size(mm) Welding Current(A) CO2 Flow Rate(L/min)
φ0.8  50~100  15
φ1.0  50~220  15~20
φ1.2  80~350  15~25
φ1.6  170~550 20~25

 Diameter 1.2MM quality welding wire ER70S-6Diameter 1.2MM quality welding wire ER70S-6Diameter 1.2MM quality welding wire ER70S-6
