Specifications
1.Professional Manufacturer2.High Quality
3.Competitive Price
4.Excellent Weldinig Performance
5.Stable Arc & Low Smoking
Welding Electrodes AWS E6013 is a low carbon steel electrode with high titanium-potassium type coating and suitable for both AC and DC. The electrode is able to provide excellent welding technological performance because the arc is extra stable and spatter loss is negligible, the slag has good fluid and solidified slag is very easy to remove, the manipulate is free and restrike is easy. It can give smooth and beautiful ripples.
High quality stick welding electrodes E6013
Reference Current (AC, DC) | |||||
Diameter(mm) |
φ2.0 |
φ2.5 |
φ3.2 |
φ4.0 |
φ5.0 |
Welding Current (A) |
40~70 |
50~90 |
90~130 |
130~210 |
170~230 |
Chemical Composition of Deposited Metal (%) | |||||
Chemical Composition |
C |
Mn |
Si |
S |
P |
Guaranteed Value |
≤0.12 |
0.3~0.6 |
≤0.35 |
≤0.035 |
≤0.040 |
Mechanical Properties of Deposited Metal | |||||
Test |
Rm(MPa) |
ReL(Mpa) |
A(%) |
KV2(J) |
KV2(J) |
Guaranteed Value |
≥420 |
≥330 |
≥17 |
-(normal temperature) |
-(0°C) |
General Properties |
460~540 |
≥340 |
18~26 |
50~80 |
≥47 |
X-ray Radiographic Inspection: 2 Degree | |||||
