Help CenterMotor Drive Bucket Elevator Gearbox
Related Products
Motor drive Bucket elevator gearbox
@Bucket elevator gearbox Features
Low noise level
Minimal vibration
High efficiency
Integrated package solution
- Mounted on a baseframe
- Backstop included
- Coupling protected by guard
Monitoring supported
Dip lubrication
@Bucket elevator gearbox designation
Water screw pumps rotate in an open concrete trough and are used to lift water in sewage treatment and drainage plants.
The screw works according to the Archimedes principle and is inclined at an angle of approximately 38°. Archimedean screw pumps are suitable for pumping heavily contaminated liquids, even those containing small solid particles. The delivery head is normally only a few meters and the flow rate relatively high.
The output shaft of the gear unit, whose mounting position corresponds to the inclination angle of the screw, does not absorb any additional loads and transmits the torque to the worm shaft by means of a flexible coupling.
Our brand gear units are specially designed to operate in these conditions. They need an adjusted oil level, a suitable shaft seal, an oil drain, and an air vent for this purpose.
Each gear unit is fitted with a backstop to prevent the screw from accelerating backwards by the water that is forced back when the motor is switched off.
@Bucket elevator gearbox Application
Municipal sewage treatment plants
Drainage plants
Irrigation systems
All applications where water has to be lifted to a higher level
