Shenzhen TW Electronics Mobile Phone Pcb Board
US$ 1 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
TWOWIN
Model Number:
TW015
Payment & Shipping
Payment Methods:
Port of Shipment:
HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Shenzhen TW Electronics Aluminium PcbUS$ 1 - 100MOQ: 1 Piece -
Shenzhen TW Electronics Induction Cooker Pcb BoardUS$ 1 - 100MOQ: 1 Piece
-
Shenzhen TW Weighing Scale PcbUS$ 1 - 100MOQ: 10 Pieces
-
Shenzhen TW Elevator PcbUS$ 1 - 100MOQ: 10 Pieces
-
Shenzhen TW Pcb PrototypeUS$ 1 - 100MOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
TWOWIN
Model Number
TW015
Base Material
fr4
Copper Thickness
1oz, 1oz
Board Thickness
1.6mm, 1.6mm
Min. Hole Size
0.5mm, 0.5mm
Min. Line Width
5mil, 5mil
Min. Line Spacing
5mil, 5mil
Surface Finishing
HASL, HASL
Specifications
mobile phone pcb board :1.thicknese:FR4 1.6MM
2.Colour:green/blue/yellow/black
3.layer:2-10
4.Finished:HASL
aluminium pcb
| ITEMS: | SPECIFICATION |
| LAYER: | 2 -10layer |
| BOARD MATERIAL: | FR-4, CEM-1,CEM-3, High TG, FR4 Halogen Free,FR-1,FR-2 |
| BOARD THICKNESS: | 0.6-3.2mm |
| CAMBER: | D>5.0+/-0.076mm 0.3<D<+/-0.05MM D<0.3+/-0.08MM |
| MIN.FINISHED HOLE SIZE: | 0.5MM |
| HOLE COPPER THICKNESS: | >20UM |
| MIN.TRACK WIDTH: | 5mill |
| MIN.TRACK SPACING: | 5mill |
| PROFILE SIZE TOLERANCE: | + / -0.15 |
| PROFILE: | MILLING,MOULDING,VUT,CHANFER |
| COATING: | HAL |
| SOLDER MASK COLOR: | green/yellow/black/white/red/blue |
| TECHNNOLOGY: | / |
| LEGEND COLOR: | green/yellow/black/white/red/blue |
| CERTIFICATE: | UL,ROHS,ISO9001,T/S 16949 |
| ASSEMBLY: | LEDA FREE,NOT LEAD FREE |
