Specifications
1. Explosion proof LED luminaire
2.
3. IP66
4.For Zone 1 and zone 2 lamp
GSD615- Explosion-proof LED lamp Explosion protected LED lighting
Explosion proof LED luminaire
- Application
Designed for explosive atmosphere areas Zone 1, Zone 2
Combustible dust areas Zone 20, Zone 21, Zone 22
Design for explosive gas IIA, IIB ,IIC, Temperature class T1~T6
- Technical parameters
Ex marks: Ex d IIC T6 Gb/DIP A20 TA,T6
Rated voltage: AC110V~264v, 50/60HZ
Rated power: 20W,30W,40W,50W,60W
Lamp type: LED
Lamp Luminous Efficiency(lm/w): over 110 lm/w
Color temperature: 5500K
Color rendering index CRI: over 75
Ingress protection: IP66
Corrosion resistance: WF2
Cable OD: 9mm to 14 mm .
- Selection Table
Model | Shape | Lamp | Power | Ex marks | Rated voltage | Ingress protection |
GSD615-20 | I | LED | 20 | Exd IIC T6 Gb,DIP A20 TA,T6 | AC110~264V | IP66 |
GSD615--30 | 30 | |||||
GSD615--40 | II | 40 | ||||
GSD615--50 | 50 | |||||
GSD615--60 | 60 |
- Products Features
Die casted of aluminum alloy high voltage electrostatic powder coated after shot blasted;
Special constant current power supply, high efficiency, low power consumption, constant output power , and has the function of short circuit
fault, open circuit fault, overheating protection,
ensure that LED light source and reliable work, fully
Play LED high photosynthetic efficiency, energy saving, long life characteristics.
