222 series Quick connect type terminal blocks
Application
1.Junction boxes:wiring of flexible conductors in a junction box
2.Industrial and Residential Lighting:Canopy lights,Halogen lamps,Lighting fixtyre connection,Interconnection of lighting fixture combinations, Through wiring on lighting fixtures, Candelabras connection, Continuous roof lights, Supply lines for decorative lighting (holiday lights, etc.)wago connector
3. Individual: individual design of low voltage system
Propety wago quick connector
|
Product group |
7 (Push Wire Conn.) |
| Cross section [mm²] | 0.08 - 2.5mm |
| Cross section [AWG] | 28 - 14AWG |
| Wiring method | s + f-st |
| Connection method | CAGE CLAMP®CONNECTION |
| Cross section [mm²] | 0.08 - 4mm² |
| Cross section [AWG] | 28 - 12AWG |
| Wiring method | f |
| Measured voltage EN | 400V |
| Measured shock voltage | 4 kV |
| Pollution degree | 2 |
| Current intensity EN | 32 A |
| Measured voltage EN | 600 V |
| Current intensity EN | 20 A |
| Weight | 6.6 g |
| Color | grey |
| Wiring type | Side-entry |
| No. of connection Points | 5 |
| No. of potentials | 1 |
| Height | 14.5 mm |
| Height | 0.571 in |
| Width | 26.6 mm |
| Width | 1.047 in |
| Depth | 20.5 mm |
| Depth | 0.807 in |
| Strip length from | 9 mm |
| Strip length to | 10 mm |
| Strip length | 0.37 in |
With advanced technology, we have gained a series of approvals, such as ISO9001:2000, CE, CB, CCC and PICC, and especially we got UL certificate for airconditioning AC contactors in 2005. We are intending to build an internationally standard factory which was accomplished in June, 2007.
We always consider quality and service first. Our policy is "Quality First; Improve Technology; Expecting Future".
Buy all kinds of contactors, cooperate with us, we will be honored and you will benefit from:
1.- Your client satisfied on the right schedule and quality;
2.- Your can get good reputation from your market and obtain more orders;
3.- Our professional service before and after sale;
4.- The reasonable price;
Packaging Detail: export standard package or designed by yourself
222 series Quick connect type terminal blocks
