high performance !1.8m or 3.2m eco solvent plotter,DX5 head printing machine for indoor ,outdoor printing

Specifications

high performance high speed
wide-area application
environmental friendly
affordable price cost efficient



Advantages

FEATURES

1. Epson DX5 printhead

 The Epson DX5 (Epson fifth generation micro-piezo print head) has a native resolution of 1440dpi

, 8 nozzle lines (corresponding with 8 independent ink channels) and 180 nozzles per line.
fast speed, high resolution printing with water-based dye and pigment inks.

Advanced intelligent head cleaning

fit-for-purpose high quality inks



2. Enhance overall performance and user comfort



3. Flexible, reliable and able to deliver excellent print quality for volume production

     runs as well as short print runs,



4. Easy to install, use and maintenance



5. Roll-to-roll printing





Application





lightbox displays, photo paper, vehicle wrap, art fabric,vinyl, PVC, PP posters,

banners, backlit signage, decals, wall coverings, point-of-sale displays,

fine art reproduction, pop-ups, stickers photo paper, vehicle wrap, art fabric,

vinyl, PVC, PP









technical specification



<

Product Name		Eco-solvent printer
Product model		DS-S
Printhead		EPSON DX5
Number of printhead		1 or 2
Max resolution		1440dpi*1440dpi
Printhead cleaning		Auto heading cleaning
Ink type		Eco-solvent ink (auto supply)
Ink color		double CMYK(2 head) CMYK(1 head)
supply		Ink cartriage auto supply
High speed Mode		2 head 35m²/hr 1 head 18m²/hr
Standard Mode speed		2 head 27m²/hr 1 head 15m²/hr
High performance speed		2 head 24m²/hr 1 head 11m²/hr
Printing material		Roll media/sheet media lightbox displays, photo paper, vehicle wrap, art fabric,vinyl, PVC, PP posters, banners, backlit signage, decals, wall coverings, point-of-sale displays, fine art reproduction, pop-ups, stickers photo paper, vehicle wrap, art fabric,vinyl, PVC, PP
Max Printing width		1.8m or 3.2m optional
Pre-heating		No
Printing heating		Yes
Post heating		Yes
feed-in system		Constant tension high-precision feed-in system
take-up system		Yes
Interface		USB 2.0
Rip software		Ultraprint RIP
Weight		200-250KG
Votage and power		220V 1200W
Machine Dimension		2900mm*800mm*1400mm
