Help CenterAluminum Coated Mylar
Related Products
Specifications
1. material: Aluminum Coated Mylar2. thickness: 10-150mic
3. width: max. 1600mm
4. color: any color
5. MOQ: 1ton
Aluminum Coated Mylar
Specification
Thickness of Film |
Thickness of Aluminum Layer |
Width |
Length |
Diameter |
Core Size |
10-150mic |
380A |
≤1600mm |
3000-36000m/r |
≤780mm |
76mm/152mm |
Technical Data
Item |
Unit |
Standard value |
Test method |
|
Thickness of film |
μm |
12 |
ASTM D-374 |
|
Tensile Strength |
MD |
Mpa |
235 |
ASTM D-882 |
TD |
241 |
|||
Elongation |
MD |
% |
126 |
ASTM D-882 |
TD |
105 |
|||
Heat shrinkage (150°C,30min) |
MD |
% |
1.6 |
ASTM D-1204 |
TD |
0 |
|||
Wetting tension |
Treatment side |
mN/m |
50 |
ASTM D-2578 |
Friction Coefficient |
—— |
0.48 |
ASTM D-1894 |
|
Haze |
% |
—— |
ASTM D-1003 |
|
Glossiness |
% |
131 |
ASTM D-2457 |
|
Thickness of Aluminum Layer |
Å |
400 |
|
|
Ω/square |
2.35 |
GB/T 15717 |
||
O.D |
2.0 |
X·Rite361 |
||
VLT |
0 |
ASTM D 1746 |
||
Equality Tolerance of Metallizing Layer |
% |
±10 |
GB/T 15717 |
|
|
Combining Fastness Tolerance of Metallizing Layer |
% |
Aluminum not fall off |
3M adhesive tape |
|
Moisture vapor transmission rate (38°C,90%RH) |
g/m2·24hr |
0.55 |
ASTM E96 |
|
Oxygen transmission rate (23°C,0%RH) |
cm3/m2·1atm·24hr |
0.88 |
ASTM D1434 |
|
Application
1. flexible packaging
2. metallic yarn
3. laminate with paper board
4. tinsel, garland
5. glitter powder
Product Performance
1. high barrier
2. strong adhesion for laminating with other material
3. bright color and reflection
4. excellent ink absorption properties.
Production Process
1. transparent film
2. metallizing
3. coating
4. slitting
5. packing
Inner Packing
1. bubble film----to protect from collision during transportation
2. specified label----factory label or customized label without factory information
Outer Packing
1. different types of packing way according to roll size or customer's request
2. wooden pallet with or without fumigation
1. free sample in A4 size or customized roll sample.
2. exact customized size of product.
3. best packing way is recommended.
4. documents, photoes of product offered before delivery.
5. long-term following up after shipping
Hangzhou Jinxin Filming Packaging Co., Ltd. is a high-tech enterprise in Hangzhou city. The company was founded in 1996, has already developed into a production value of billions of dollars, well-known at home and abroad for vacuum metalized film business. Mostly we export to USA, Japan, Germany, Canada, France, turkey, Pakistan, Malaysia, Indonesia, Philippine, Vietnam, Mexico, and etc.
The main products of our company is metalized PET/CPP/OPP/PE film, metalized PET film + PE, rainbow film, holographic film and other types of film, widely used in medicine, food, building materials, electronic components packaging and textile clothing, decoration, glass film industry.
In 2011, the company was moved into the Linjiang Industrial Zone of Xiaoshan District, covers an area more than 20000m2, the total investment about 10million US dollar, with an annual output of various types of metalized products 15000 tons. Company has staff 100 people, more than 30% of staff have college education.
Every year, companies invest a lot of money for new product development and technological upgrading, with a number of technology patents for inventions and utility model patents and other core technology. “Yarn grade metalized PET film, pure silver metalized film” project, as the Hangzhou City Economic Development Bureau and Bureau of science and technology projects. The company’s “Xinsheng” registered trademark, renowned at home and abroad. Welcome all the guests to visit the company.
1. detailed information is required before quoting. For example, thickness, width, length, application and quantity.
2. size, color and packing way can be customized.
3. weekly updated price.
4. payment: T/T or L/C at sight.
5. delivery time: 20 days after receiving down payment.
6. any question please do not hesitate to contact us.
