Needle Roller Bearings are rotational motion bearings in which a thin needle-shaped roller is incorporated into a rolling element. They have a low cross-section height and high load capacity compared with ball bearings.
Characteristics
Radial compact structure, a smaller cross-section.
igher load-carrying capacity, greater rigidity.
Lower inertia forces that facilitate size and weight reductions in machinery.
Application
They’re designed to withstand oscillation, perform under severe conditions, and interchange with sliding bearings. Diverse types of needle bearings are available in a wide variety of sizes and tolerances, for a multitude of applications.
Series
---Metric series: NA,NAF,TRI,TATF,HK, BK, F, FH, FY, MF, MFH, MFY; TA.. Z, TLA.. Z, TAM, TLAM, YT, YTL.
---Inch series: SCE, BCE, SCH, BCH, SN, B, BH, M, MH,; BA... Z, BHA... Z, BAM, BHAM, YB, YBH.
MORE SIZE , CONTACT US DIRECTLY. Large stock for Sweden famous brand, Japan brand NSK bearings, fast delivery for all type
|
Bearing No. |
d | D | B |
weight g |
| NA4900 | 10 | 22 | 13 | 23 |
| NA4901 | 12 | 24 | 13 | 26 |
| NA4902 | 15 | 28 | 14 | 34 |
| NA4903 | 17 | 30 | 13 | 37 |
| NA4904 | 20 | 37 | 17 | 75.2 |
| NA4905 | 25 | 42 | 17 | 88 |
| NA4906 | 30 | 47 | 17 | 101 |
| NA4907 | 35 | 55 | 20 | 170 |
| NA4908 | 40 | 62 | 22 | 252 |
| NA4909 | 45 | 68 | 22 | 290 |
| NA4910 | 50 | 72 | 22 | 274 |
| NA4911 | 55 | 80 | 25 | 393 |
| NA4912 | 60 | 85 | 25 | 426 |
| NA4913 | 65 | 90 | 25 | 456 |
| NA4914 | 70 | 100 | 30 | 728 |
| NA4915 | 75 | 105 | 30 | 775 |
| NA4916 | 80 | 110 | 30 | 878 |
| NA4917 | 85 | 120 | 35 | 1250 |
| NA4918 | 90 | 125 | 35 | 1312 |
| NA4919 | 95 | 130 | 35 | 1371 |
| NA4920 | 100 | 140 | 40 | 1900 |
| NA4922 | 110 | 150 | 40 | 2070 |
| NA4924 | 120 | 165 | 45 | 2860 |
| NA4926 | 130 | 180 | 50 | 3900 |
| NA4928 | 140 | 190 | 50 | 4150 |
| Model | Old Items | Code(dxDxB) | Weight/kg |
| NAV4011 | 4074111 | 55x90x35 | 1.03 |
| NAV4013 | 4074113 | 65x100x35 | 1.2 |
| NAV4014 | 4074114 | 70x110x40 | 1.702 |
| NAV4015 | 4074115 | 75x115x40 | 1.81 |
| NAV4016 | 4074116 | 80x125x45 | 2.47 |
| NAV4017 | 4074117 | 85x130x45 | 2.58 |
| NAV4822X3 | 74822 | 110x145x32 | |
| NAV4864X3 | 74764 | 320x410x75 | 28.7 |
| NAV5840X3 | 74740 | 200x260x65 | 10.3 |
| NAV2920X3 | 74820 | 100x145x32 | 1.69 |
| NAV4908X1 | 74708 | 40x65x22 | 0.334 |
| NAV4909X1 | 74709 | 45x72x22 | 0.338 |
| NAV4920X1 | 74720 | 100x135x40 | 1.9 |
| NAV4924X1 | 74724 | 120x160x40 | |
| NAV4000X1 | 74800 | 10x28x16 | 0.061 |
| NAV3011X3 | 74711 | 55x85x28 | 0.677 |
| NAV3013X3 | 74713 | 65x95x28 | 0.781 |
| RNAV3905 | 3084905 | (FwxDxB)30x52x25 | |
| RNAV4902 | 4084902 | (FwxDxB)20x28x13 | 0.029 |
| RNAV4903 | 4084903 | (FwxDxB)22x30x13 | |
| RNAV4904 | 4084904 | (FwxDxB)25x37x17 | |
| RNAV4905 | 4084905 | (FwxDxB)30x42x17 | 0.0661 |
| RNAV4906 | 4084906 | (FwxDxB)35x47x17 | 0.075 |
| RNAV4907 | 4084907 | (FwxDxB)42x55x20 | 0.14 |
| RNAV4908 | 4084908 | (FwxDxB)48x62x22 | |
| RNAV4909 | 4084909 | (FwxDxB)52x68x22 | |
| RNAV4910 | 4084910 | 58x72x22 | 0.213 |
| RNAV4912 | 4084912 | 68x85x25 | 0.33 |
| RNAV4914 | 4084914 | 80x100x30 | 0.444 |
| RNAV4916 | 4084916K | 90x110x30 | |
| RNAV4918 | 4084918 | 105x125x35 | 0.929 |
| RNAV4919 | 4084919E | 110x130x35 | |
| RNAV4920 | 4084920E | 115x140x40 | |
| RNAV4922 | 4084922E | 125x150x40 | |
| RNAV4924 | 4084924E | 135x165x45 | |
| RNAV4926 | 4084926E | 150x180x50 | |
| RNAV6902 | 6084902 | 19.8x28x23 | 0.0471 |
| RNAV6904 | 6084904 | 25x37x30 | 0.089 |
| RNAV6907 | 6084907 | 35x50x40 | 0.293 |
| RNAV4002 | 4084102 | (FwxDxB)21.7x32x17 | 0.0536 |
| RNAV4003 | 4084103 | (FwxDxB)24.3x35x18 | 0.065 |
| RNAV4004 | 4084104 | (FwxDxB)28.7x42x22 | 0.118 |
| RNAV4005 | 4084105 | (FwxDxB)33.5x47x22 | 0.134 |
| RNAV4006 | 4084106 | (FwxDxB)40.1x55x25 | 0.201 |
| RNAV4007 | 4084107 | (FwxDxB)45.9x62x27 | 0.269 |
| RNAV4008 | 4084108 | (FwxDxB)51.6x68x28 | 0.311 |
| RNAV4009 | 4084109 | (FwxDxB)57.4x75x30 | 0.4 |
| RNAV4010 | 4084110 | (FwxDxB)62.1x80x30 | 0.438 |
| RNAV4011 | 4084111 | (FwxDxB)69.8x90x35 | 0.6 |
| RNAV4012 | 4084112 | (FwxDxB)74.6x95x35 | 0.7 |
| RNAV4013 | 4084113 | (FwxDxB)80.3x100x35 | 0.72 |
| RNAV4014 | 4084114 | (FwxDxB)88x110x40 | 1 |
| RNAV4015 | 4084115 | 92.7x115x40 | 1.07 |
| RNAV4016 | 4084116 | 100.3x125x45 | 1.44 |
| RNAV4017 | 4084117 | 104.8x130x45 | |
| RNAV602 | 84904 | 20x42x80 | |
| RNAV604 | 84905 | 25.4x52x84 | |
| RNAV606 | 84906 | 32x45x32 | 0.167 |
| 30 | HK3012 | 27941/30 | 30 | 37 | 12 | 9300 | 14600 | 4800 | 7300 | 0.02365 |
| HK3016 | 47941/30 | 30 | 37 | 16 | 14100 | 24700 | 4800 | 7300 | 0.03070 | |
| HK3016-RS | 30 | 37 | 16 | 13000 | 22400 | 4800 | 7300 | 0.03010 | ||
| HK3020 | 67941/30 | 30 | 37 | 20 | 18500 | 34500 | 4800 | 7300 | 0.04860 | |
| HK3020/AS1 | 30 | 37 | 20 | 18100 | 34000 | 4800 | 7300 | 0.04852 | ||
| HK303816 | 7941/30 | 30 | 38 | 16 | 15700 | 24900 | 4800 | 7300 | 0.03750 | |
| HK303816/AS1 | 30 | 38 | 16 | 29600 | 49200 | 4800 | 7300 | 0.03796 | ||
| HK303824 | 7942/30 | 30 | 38 | 24 | 24500 | 44100 | 4800 | 7300 | 0.05880 | |
| HK303832 | 7943/30 | 30 | 38 | 32 | 31400 | 60700 | 4800 | 7300 | 0.07390 |
Q. How to place an order?
A. Send us enquiry directly at the bottom, give us the bearing model with quanity, Brand,material, payments way,or other special requirements you want.
Q. Can I get a sample order?
A. Yes, you can. It depends on the total quantity and price.
Q. What is the smallest order can you accept?
A. The total amount can not below USD500.00 not including shipping fee.
Q. What is the delivery payments ?
A. EXW, FOB, CIF, CFR , you can choose.
Q. What's the shippping way ?
A. Sea transportation, DHL, TNT, UPS,FEDEX, as per your requirements.
Q. What is the lead time?
A. 5-7 days for small order in stock; 15-30 days for large order.
