home appliance borosilicate glasshigh resistance to thermal shock
low coefficient of expasion
competitive price
home appliance borosilicate glass
I. Application
1). Household electrical appliance (panel for oven and fireplace, microwave tray etc.);
2). Environmental engineering and chemical engineering (lining layer of repellence, autoclave of chemical reaction and safety spectacles);
3). Lighting (spotlight and protective glass for jumbo power of floodlight);
4). Power regeneration by solar energy (solar cell base plate);
5). Fine instruments (optical filter);
6). Semi-conductor technology (LCD disc, display glass);
7). Iatrology and bio-engineering;
8). Safety protection (bullet proof glass)
II. Specification of Product
1) Dimensions: 1200mm×600mm 1200mm×900mm 1200mm×1800mm other formats upon request
2) Available thickness: 2mm--12mm, 15mm, 20mm
3) Net sized glass of strengthening can be supplied as per the customers requirement;
4) Glass of small cut size is available according the requirement from customers.
III. Performance of the Product
1). Mechanical Performance
Density ρ 2.23±0.02g/cm3
2). Thermodynamic Performance
Thermal expansion coefficient (0-300) 3.3±0.1×10-6K-1
Softening point 820±10
Strain point 516±10
Caloricity (20-100) 0.82KJ × (kg×K)-1
Thermal coefficient 1.2W×m×K-1
Thermal shock resistance 180K
Strengthening type 300K
Identical temperature difference 100K
Strengthening type 300 K
Maximum working temperature Short time(<10h): 500
Long time(>10h): 450
3). Chemical Performance
Water resistance ISO719/DIN12111 HGB1/ISO720 HGA1
Acid resistance ISO1776/DIN12116 1
Alkali resistance ISO695/DIN52322 A2
4). Optical Property
Refractive index Nd: 1.47384
Transmittance spectrum curve
5). Electrical Property
Specific resistance lgρ 8.0Ω×cm at 250
Dielectric dissipation fraction tan σ (1 megacycle at 20): 38×10-4
Dielectric constant ε=4.7
The above mentioned specifications are in conformity with standard of ISO3585 after inspection and detection as well as examination by the Quality Supervision and Inspection Center of the National Light Industry for Glass Product and, Beijing Glass & Ceramic Quality Supervision and Inspection Center.
IV. Means of Processing for Customers
Cutting
Round corner
Round edge
Surface fine polishing
Hole drilling
Coating
Surface printing and sand blasting
Thermal bendin
Look forward to doing business with you!!!
