Small Packing Machine with Volumetric Cup (pack granule) or Auger (pack powder)
Potato Chips Vertical Packing Machine HTL-420C |
https://youtu.be/zoNisvz324Q |
Food Rotary Packing Machine HT-8G |
https://youtu.be/_dE9ARewCr8 |
Small Granule Packing Machine HTL-400A |
https://youtu.be/yt3ulgZiehk |
Small Powder Packing Machine HTL-400F |
https://youtu.be/jCMy3GmEDYs |
Vertical Powder Packing Machine HTL-420F |
https://youtu.be/vY_VJA8LjzI |
Zipper Pouch Rotary Packing Machine HT-8F |
https://youtu.be/WhiTwPWwOts |
1.The small packaging machine is fully automated operation, it can achieve product packing assembly line work, and improving production efficiency and significantly reduce product cost.
2.The vertical small packaging machine conforms to the food processing machinery’s sanitation standard. On the machine, the spare part which contacts the material and pouch conforms to the standard of food sanitation request on material processing, food health and security guarantee.
1. With the function auto filling, measuring, bag forming, code printing, sealing and cutting. Bag-making system adopts step motor with high precision
2. Controller adopts Chinese or English displaying, can see the working conditions directly.
3. With intelligent photoelectric controller system.
4. Machine body full of 304 stainless steel.
5. Cup volumetric filler, high accuracy.
6. Good visibility with side-open protective platens, operate safely.
7. Adopt the newest hopper sets, easy to adjust and clean, no need adjust again after clean, so
that can improve working efficiency
8. This machine is suitable for the packing of granule products, bag can choose from 3-side or 4-side seal or back seal according to customer needs.
9. Ribbon printer is addable according to customer needs, which can print one to three lines
letter, date of produce and batch number.
10. The Bag Former: The bag width is different , the former is different
11. The Bag Length :Could be set on the Operate Interface
Model |
HTL-400A |
Packing Speed |
30-70 bags/min |
Bag-Making Size |
Width 30-150mm, Length 50-200mm |
Filling Range |
1-500g |
Packing Materials |
OPP/CPP PET/PE PET-AL/PE composite material |
Film Width |
80-320mm |
Film thickness |
0.04-0.08mm |
Film Roll Diameter |
Max. 320mm |
Power Supply |
AC220V/380V 50/60Hz 2.5kw |
Machine Dimensions |
(L)1200*(W)900*(H)2150mm |
Machine Weight |
300kgs |
