Help Center12v 32ah 36b20r mf Car Battery
Related Products
-
Auto Battery Dry Charged Car Battery 3k BatteryUS$ 78 - 79MOQ: 30 Pieces -
Car Battery 12v 75ah Maintenance Free Auto Battery for TruckUS$ 20 - 58MOQ: 100 Pieces
-
Good Quality 12V 75AH Maintenance Free Car BatteryUS$ 20 - 55MOQ: 100 Pieces
-
JIS Standard and DIN Standard Car Battery Ns60 12v 45ahUS$ 23 - 26MOQ: 50 Pieces
-
OEM/ODM Maintenance Free 80d26l mf 12v70ah Car BatteryUS$ 20 - 55MOQ: 100 Pieces
Specification car Battery
| Model |
Picture |
Nominal Voltage (V) |
Nominal Capacity C20(ah) |
CCA (A)-18°c |
External Dimension (L*W*H*TH)mm |
Lay-out |
Terminal Type |
Weight | |
|
Dry (Kg) |
Wet (Kg) |
||||||||
| NS40 | 12V | 32Ah | 274A | 196*130*190*220 |
1/ 0 | A/B | 6.6 | / | |
Construction car Battery
| Component | Positive | Negative | Clapboard | Eletrolyte | Terminal |
| Raw Material | Lead Dioxide | Lead | Rubber | Sulfuric Acid | Copper |
Packing and Shipping
1. Packing : one pcs/polybag+carton+pallet,Or as your Requirements
2.Payment :L/C,T/T,Westor Union
3.Delivery Date :10-20 Day
4.Shipment Type:By Sea,By air,ect
Hottest sale Dry charged car battery
| Model |
Battery standard
|
Voltage (v) |
Capacity (ah) |
CCA (A) |
RC (min) |
Terminal type |
Lay-out |
Dimension (L*W*H*TH)mm |
Weight (Kg) |
| N32 | JIS | 12 | 32 | 210 | 52 | E | 1/0 | 195*130*165*195 | 6.8 |
| N36 | JIS | 12 | 36 | 274 | 56 | B | 1/0 | 200*130*200*220 | 7.1 |
| N45 | JIS | 12 | 45 | 325 | 71 | A/B | 1/0 | 240*130*200*220 | 8.4 |
| N60 | JIS | 12 | 60 | 390 | 100 | A | 1/0 | 260*170*200*220 | 10.2 |
| N70 | JIS | 12 | 70 | 430 | 113 | A | 1/0 | 310*170*200*220 | 11.6 |
| N100 | JIS | 12 | 100 | 440 | 180 | A | 1/0 | 410*175*205*225 | 16.4 |
| N120 | JIS | 12 | 120 | 638 | 230 | A | 3 | 505*180*210*235 | 19.1 |
| N200 | JIS | 12 | 200 | 1000 | 430 | A | 3 | 514*265*212*235 | 29.5 |
| DIN45 | DIN | 12 | 45 | 220 | 75 | A | 1/0 | 237*128*220 | 8.4 |
| DIN50 | DIN | 12 | 50 | 330 | 80 | A | 1/0 |
245*175*175 210*175*190 |
8.8 |
| DIN60 | DIN | 12 | 60 | 360 | 100 | A | 1/0 |
245*175*175 260*172*225 245*175*190 |
10.9 |
| DIN70 | DIN | 12 | 70 | 430 | 113 | A | 1/0 | 260*172*225 |
11.8 |
| DIN100 | DIN | 12 | 100 | 440 | 180 | A | 1/0 | 352*175*190 |
13.9 |
Dry charged car Battery Feature
♦ High Power Density
♦ Thick Plates and High Density Active Material
♦ Longer Use Life:5-10Years
♦ Excellent Recovery From Deep Discharge
♦ Wide Work Temperature Range :-40°c~+70°c
♦ Reliable Safety Value,No Leakage,No Acidic Gas Apillage
♦ Good Internal Water Cycling
♦ Low Internal Resistance,Compact,Excellent Discharge Performance
♦ Low Self Discharge,Good Storage Life
♦ Long Time Design Life :10-20Year
♦ Long Time Warranty:12 Month
Battery Application
The Battery Widely Use in Cars ,Buses,Other Vehicles,ect
our Advantage:
* We are Professional Manufacturing automobile battery
* We Have 18 Internatinal Trade Experience,Export to all over the world
* Our products Have Long Time Warranty
* We offer to High Quality Products With Competitive Price
* We Have CE ROSH UL SGS ISO9001:2000 Certification
Warming
1, when the lead-acid battery, to wear protective clothing
2, charging, spark near the battery can not ban smoking.
3, when one or more batteries in parallel charging, the charger voltage does not exceed 16V.
4, the positive lead from the charger connected to the positive pole of the battery, the negative wire to the negative pole of the battery.
5, when you open the charger, the first set to the minimum current, and then gradually increase the current until the battery started to accept current. If the battery after a deep discharge battery or low temperatures, this process may take several minutes.
6, if the battery is discharged exhaust mist, or the battery temperature exceeds 52 degrees Celsius, the charge that is required to immediately stop these phenomena indicate that the battery is damaged and need replacing.
7, when the current drops below 1A or charging more than 24 hours after charging is completed, you can stop the charge.
A professional battery manufacturer
Shenzhen Eastar Battery Co., Ltd was set up as a manufacturer of various batteries in 1997. Our main products include dry batteries ( carbon & alkaline), lead-acid batteries(General batteries, Auto batteries), Ni-MH/Ni-CD batteries and packs, Lithium batteries ( Li-ion, Li-PO). With six manufacturing facilities of around 200,000 square meters, and a team of highly qualified staff, Eastar grew up as a professional battery group in Southern China.
Quality is our life
As a battery manufacturing group, we have separate factory located in Guangzhou, Shenzhen and Xingfeng for different battery types. We understand well on the importance of the quality, so we invested much on the advanced production facilities and testing equipments. We have a powerful R&D and skillful worker group. Based on ISO9001, we built up a complete quality control system. We always keep ourselves working ahead on technology and quality control in battery field.
The best services to you
We built up our sales team with 20 saleswomen/ salesmen in down town Shenzhen. Our team is a experienced sales team, Our motto is: EVERY TIME THE BEST SERVICES TO EVERY CUSTOMER. We are good at both ODM orders and OEM projects. If you are in battery business, come to us, I believe you will find that you are working with the right partner: Shenzhen Eastar Battery Co., Ltd.
Certification
