3 Ways Pneumatic Suction Chain Cutter Device With JUK Over-lock Machine
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Semi-Automatic
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
zhongshan/Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chain Removal Suction Device Wiht Flat Seamer MachineNegotiableMOQ: 1 Piece -
Waste & Dust Removal Vacuum System of Flat-lock MachineNegotiableMOQ: 1 Piece
-
Pneumatic Suction Device With Lockstitch MachineNegotiableMOQ: 1 Unit
-
Chain Removal Suction Device With Flat Seamer MachineNegotiableMOQ: 1 Piece
-
Automatic Chain Removal Suction Device With Flat Seamer MachineNegotiableMOQ: 1 Piece
Condition
New
Automatic Grade
Semi-Automatic
Place of Origin
Guangdong, China
Brand Name
GRAND
Model Number
CA112-1-P-F-SC( JUKI)
Certification
ISO9001:2008;CE;UKAS Certificate
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
ISO9001:2008;CE;UKAS Certificate1.low Noise,
2.Easy to use,
3.Latest Type,
4.Convenient,
Advantages of sewing machine installing chain cutter dust suction device?
1, work site clean
2, equipment clean
3, does not require any operational requirements, novices can be quickly reached the level of skilled
4, save sissors threads workers
5, to improve the production efficiency 20%
GRAND brand Chain cutter dust suction device works: air compressor pressure generated by the vacuum generator after amplification (or small vacuum motor) produces powerful suction, the former Qiebu inhalation trash, after priming package after the completion of the sewing inhalation internal sutures knife, aim to achieve by trimming blade reciprocates.
Effect: provincial lines, job site clean, equipment cleaning, save costs and improve productivity.
Application: Suitable for all brands of sewing sewing machine supporting the use of the installation.
JUKI-6700S over-lock machine Configure & installation diagram :
Pneumatic suction dust collector kind Legend:
Suction device product patent description:
Description of Key Components:
SC Self-cleaning application effect:
| Name: | 3 Ways Pneumatic Suction Chain Cutter Device With over-lock Machine (with JUKI over-lock machine as an example:front waste + chain vacuum removal + foot lifter) |
| Model: | GA112-1-P-F-SC-JUKI Derived Model: GA111-1 1 way (front waste or chain vacuum removal) GA111A-1 1 way front waste GA112-1 2 ways (front waste + chain vacuum removal) GA112-1-P 3 ways (front waste + chain vacuum removal + foot lifter) |
| Description: | This series of products applies to thread-cutting and suction for overlock sewing machine in Garment manufacturing company. The device should be used with a central gas distribution (or mini air compressor). It can be custom made into three model. 1 way (front waste or chain vacuum removal, you can choose one of them), 2 ways (front waste plus chain vacuum removal) , 3 ways (front waste plus chain vacuum removal plus foot lifter). This device is primarily driven by pneumatic components. Air source comes through the valve,then pushes air component working well. Thread and scraps of cloth are sucked by this device. When you press the foot lifter, valve automatically reset, device will be power off due to short of air source. This small size device has effective thread-cutting and suction function, which is easy to operate and can keep workshop clean. |
| Feature: | 1.Venturi operates when treadle pressed; 2. PL controller operates when treadle heeled; 3. Can be used with any kind of over-lock or inter-lock machine; 4.Air regulator assembly is optional; 5.Self-cleaning is optional(upper looper dust removal) |
| Scution Device Order Guide:GA 11 2 -2 - P - D - F - SCGE 10 2 -2 - BL | |||
| GA/GE | GA means Air Action GE means Electirc Action |
1/2/4 | 1 means fabric suction bag 2 means round plastic bucket 4 means iron box |
| 10/20/30/11/21/31 | 10 Means Round Style Suction Cover for Overlock M/C 20 Means Round Style Suction Cover for Flatlock M/C 20 Means Round Style Suction Cover for Feed Off Arm M/C 11 Means Square Drawer Suction Cover for Overlock M/C 21 Means Square Drawer Suction Cover for Flatlock M/C 31 Means Square Drawer Suction Cover for Feed Off Arm M/C |
S/S2 | S means single solenoid valve S2 means doubel solenoid valves |
| P | P means cylinder(foot lifter) | ||
| D | D means Full-submergence bracket | ||
| F | F means air regulator(Filter) | ||
| SC | SC means upper looper dust removal(self-cleaning) | ||
| 1/1A/2 | 1 Means 1 way chain removal only 1A Means 1 way waste vacuum only 2 Means 2 ways chain removal+waste vacuum |
BL/HB | BL means Brushless Motor Scution HB means Suction Brush Motor |
Chain Cutter Optional:
| MACHINE BRAND | CHAIN CUTTER MODE | MACHINE MODEL |
| JUKI | TO-45 TO-42 (Side) | MO-2514, 3314 3714, 3914, 6714, 6914 |
| TO-35 TO-41 (Flat) | MO-2516, 3316 3716, 3916, 6716, 6916 | |
| YAMOTO | 2109917(K2) (Side) | AZ-8003, AZ-8020, CZ-6003, CZ-6125 |
| 2109906(K1) (Flat) | AZ-8500, AZ-8600, CZ6520, CZ6500 | |
| BROTHER | S24273-001 (Side) | N11, N21, V61 |
| S43547-001 (Flat) | N31, V51 | |
| PEGASUS | KS-308046-91 KS-304294-91Y (Side) | EX5214, MX5214 M752, M852 |
| KH-308020A-91 KH-304308-91Y (Flat) | EX3216, MX3216 M732, M832 | |
| SIRUBA | KS-301148 KS-308046-91 (Side) | 737, 747F, 747D, E52 988-504, 747K |
| KH-301235 KH-308020A (Flat) | 757F, 757D, 767F, E32 988-516, 757K | |
| KINGTEX | SS023 KS-308046-91 (Side) | SH7004 UH9004 |
| SS035 KH-308020A (Flat) | SH7005 UH9005 |
Other cutter model not listed, please contact with the company engineers!
