Specifications
Automatic operation with high speedUsed for packing water,juice,milk,yoghurt bottles,cans
Saving labor cost
It is a fully automatic L sealer,widely used in pipelining work for large quantity package with high work efficiency,installed with pin hole device,adjustable film feeding system and adjustable conveying table,meets different requirements for different products FQL-450LA has a kissing device for packing the small products.Adopts heat resistant alloy cutter plated Teflon,results in good sealing ,without melting the film and any smoke pollution.Assembles one horizontal and one erect sensor for the entrance to the sealer it is easy to switch over ,even for some thin products,it is also easy to pack them.The length of film feeding,controlled by magic eye and counter,also fixes an inductive motor for collecting wasted film automatically.The machine fixes an organic safty glass cover,with alarm function,so that the operator is safe. The machine can be connected with the production line, which is no need additional operators.
Specifications:
SEALING & CUTTING UNIT | |
Sealing type |
L sealing by types of L bar |
Power Supply |
380V 50Hz 3 Phase |
Max Power |
1.5KW |
Packing Speed |
35 paks/min |
L bar sealing size |
570*480mm |
Sealing height |
125mm |
Film type |
Center-folded POF film |
Working table height |
800-950mm |
Air pressure |
0.5Mpa |
Sealing system |
Permanently heated seal bar with easy exchangable sealing without odorous |
Machine size |
1600*600*1260mm |
Weight |
360KG |
Our company has rich experience to help customers to establish the different production lines for different use, for example. we can arrange technical staff to help customer set up whole production line for mineral water, pure water,coca-cola, milk, juice and vinegar,oil, we are profession for making it. If anyone who is interested in such field wants to buy the whole equipments and machines, pls contact us freely.
We warmly welcome customer to visit our factory at any time,you will see the machine working and running
conditon in our factory!
