Specifications
kaolin granulator:1.Granulating rate>95%
2.more professional
3.reliable performance
4. convenient maintenance
Application of disc granulator it is one of common equipments in compound fertilizer industry. Generally, it is applicable to smaller scale fertilizer production of medium and low concentration. The slope degree of its pan can be adjusted from 40 degree to 55 degree.
1.Advantages of kaolin granulator
1) High granulating rate, more than 93%, homogeneous grain.
2) Reliable quality, the pan is made of thicken steel plate, never be out of shape.
3) Easy to operate, convenient maintenance.
2.Working principle of kaolin granulator
the pan revolves at a certain angle with the horizontal plane driven by the motor through reducer. The powder will rise along with the revolving pan under the friction between the powder and the pan, on the other hand, the powder will fall down under the function of its gravity. At the same time, the powder is to the pan edge because of the centrifugal force. The powder material rolls in a certain trace under the function of these three forces. It gradually becomes the required size, then overflows by the pan edge
3.Technical parameters of kaolin granulator :
Model |
ZL1.8 |
ZL2.2 |
ZL2.5 |
ZL2.8 |
ZL3.0 |
ZL3.2 |
ZL3.6 |
ZL4.5 |
Disc dia.(mm) |
1800 |
2200 |
2500 |
2800 |
3000 |
3200 |
3600 |
4500 |
Disc edge height (mm) |
500 |
500 |
500 |
600 |
600 |
600 |
600 |
600 |
Input size(mm) |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
Discharging size(mm) |
2-6 |
2-6 |
2-6 |
2-6 |
2-6 |
2-6 |
2-6 |
2-6 |
Volume (m3) |
1.14 |
1.9 |
2.5 |
3.7 |
4.2 |
4.8 |
6.1 |
6.1 |
Rotation speed(r/min) |
13.6 |
13.6 |
13.6 |
13.6 |
13.6 |
13.6 |
13.6 |
12.28 |
Power(KW) |
4 |
5.5 |
7.5 |
11 |
11 |
11 |
15 |
30 |
Capacity(T/H) |
0.5-1 |
0.8-1.2 |
1-1.5 |
1-2.5 |
2-3 |
2-5 |
3-5 |
10 |
Weight(kg) |
2.2 |
2.8 |
3.2 |
3.7 |
4.3 |
5.1 |
6.5 |
7.9 |
