Specifications
1.high penetration rate2.unique clockwise and anti-clockwise rotation
3.excellent air sealing and control
4.little virbratio
RC hammer:the exhaust air,and cuttings are discharge through the center return hole of the RC hammer,and the exhaust air is not discharged into the ground,It creates excellent up-hole velocity,which ensure cuttings are quickly removed from the bit face providing an extremely clean hole and excellent life time on the bit.
1.Main specifications:
TH1162RC--- RE543
TH1214RC--- RE040
TH1261RC--- RE052
TH1305RC--- RE054
TH1307RC--- RE140
2.Application range: Geological exploration, ore mining.
3.Design Principles: To arrive at target depth exactly and improve the productive efficiency with low cost, durable using.
4.Outstanding advantages: High impact frequency, fast penetration rate, low air consumption, high crush function, low cost,precise rock sample.
5.Main specifications and parameters:
Hammer Bit range.mm Cylinder O.D Working pressure
TH1162 121-133 116mm 250-500
TH1214 127-137 121mm 250-500
TH1261 133-143 126mm 250-500
TH1305 137-146 130mm 250-500
TH1307 137-146 130mm 250-500
Technical Parameters
Description |
Product Code |
Outside Dia. (mm) |
Length Without Bit (mm) |
Weight(kg) |
Flat Wrench (mm) |
Rec. Hole Size (mm) |
|||
TH126RC |
248000 |
126 |
1273 |
67 |
94 |
140-160 |
|||
Working Pressure (bar) |
17Impact Frequency at 17 bar(Hz) |
Normal Axial Pressure(kN) |
Recommended Rotation Speed (r/min) |
Air Consumption (m³/min) |
|||||
12-24 |
25 |
9.2 |
30-50 |
12bar |
17bar |
24bar |
|||
8.2 |
14.9 |
23.4 |
|||||||
Main Specification------TH80RC, TH98RC, TH126RC, TH140RC, TH180RC, TH220RC | |||||||||
