Help Center14"TS330 DTH Hammer for Oil,deep Hole Drilling
Related Products
Specifications
1.For oil deep hole drilling2.Simple structure and easy operation
3.Reliable performance
4.Long service life
Usage:
drilling holes from 445mm to 600mm.
Application Range:
To drill deep holes for oil and gas exploitation,water well, and other projects boring holes with depth 300 meters above and diameters 216mm above.
Design Principles:
Mostly increase the reliability of drilling tools to overcome difficulties caused by underground complications.
Features:
Reliable performance
Easy to disassemble and assemble
Technical Parameter:
Description |
Product Code |
Bit Shank |
Thread Connection |
Outside Dia. (mm) |
Length Without Bit (mm) |
Weight (kg) |
Flat Wrench (mm) |
Rec. Hole Size (mm) |
||
TS330 |
440000 |
TS330 |
API 7 5/8" REG PIN |
330 |
2389 |
1030 |
_ |
445-600 |
||
|
Working Pressure (bar) |
Impact Frequency at 17 bar(Hz) |
Normal Axial Pressure(kN) |
Recommended Rotation Speed(r/min) |
Air Consumption(m³/min) |
||||||
17-24 |
16 |
31.5 |
30-40 |
17bar |
21bar |
24bar |
||||
49.3 |
62.5 |
70.3 |
||||||||
Picture:
