G80 CHAIN

G80 CHAIN thumbnail-1
G80 CHAIN photo-1
Negotiable MOQ: 100 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
ALPHAY
Model Number:
G80
Contact Supplier Request Quote Chat Now
Jiangsu Alphay International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Nantong or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name ALPHAY
Model Number G80
Structure Welded Chain
Function Conveyor Chain
Material Alloy
Standard or Nonstandard Standard

Specifications

G80 CHAIN FOR LIFTING OR HOIST
SIZE:4-32MM
SURFACE TREATMENT:RED PAINTED





G80 CHAIN

MERTAIL:HIGH QUALITY ALLOY STEEL

SURFACE TREATMENT:SELF COLOR,POLISHING,BLACKENED,PAINTED,PLASTIC,COATING,HOT DIP GALVANIZE, ELECTRO-GALVANIZE, ETC

QUALITY GRADE:G80

SAFETY FACTOR:MIN 4

PRODUCT MARKING:G80 OR REQUIRED BY CLIENT

STANDARD:EN818-2/EN818-7

Nominal
    diameter		 Weld diameter Pitch Width Weight Working load Proof load Breaking load Deflection   bending
d tolerance ds   max. t t   max. t   min. b1   min. b2   max. Kg/m Kg kN   min. kN   min. min.
4 ±0.16 4.4 12 12.4 11.6 5.2 14.8 0.35 500 12.6 20.1 3.2
5 ±0.2 5.5 15 15.5 14.6 6.5 18.5 0.5 800 19.6 31.4 4
6 ±0.24 6.6 18 18.5 17.5 7.8 22.2 0.8 1120 28.3 45.2 4.8
7 ±0.28 7.7 21 21.6 20.4 9.1 25.9 1.1 1500 38.5 61.6 5.6
8 ±0.32 8.8 24 24.7 23.3 10.4 29.6 1.4 2000 50.3 80.4 6.4
10 ±0.4 11 30 30.9 29.1 13 37 2.2 3150 78.5 126 8
13 ±0.52 14.3 39 40.2 37.8 16.9 48.1 3.8 5300 133 212 10
16 ±0.64 17.6 48 49.4 46.6 20.8 59.2 5.7 8000 201 322 13
18 ±0.9 19.8 54 55.6 52.4 23.4 66.6 7.3 10000 254 407 14
19 ±1 20.9 57 58.7 55.3 24.7 70.3 8.1 11200 284 454 15
20 ±1 22 60 61.8 58.2 26 74 9 12500 314 503 16
22 ±1.1 24.2 66 68 64 28.6 81.4 10.9 15000 380 608 18
23 ±1.2 25.3 69 71.1 66.9 29.9 85.1 12 16000 415 665 18
25 ±1.3 27.5 75 77.3 72.8 32.5 92.5 14.1 20000 491 785 20
26 ±1.3 28.6 78 80.3 75.7 33.8 96.2 15.2 21200 531 849 21
