Automatic Paper Machine ZWJK-1600 Frame Type Overfeed High Speed Paper Rewinder

 Frame-type Downward Rewinder

Technical Proposal

 I:overview

ZWJK Frame-type High-speed downward Rewinder, is used for slitting the first-rolled original paper roll, rewinding it to the finished paper roll which comply with the width and tightness demand.

 The machine has two types. Facing with the paper-out side, if the drive part is on the right side, then it is right-hand machine, vice versa. The customer can choose the type according to personal demand.

II:Technical Parameter

1:trim width:             1600mm

2:paper picking up way:       downward

3:GSM:             80—300g/m*m

4:the max dia of original paper roll:         φ1250mm

5:the max dia of finished paper roll:           φ1250mm

6:working speed:              600m/min

8:supporting roll dia:             φ420mm

9:machine frame center distance:             2780mm

10:supporting roll center distance:           2300mm

11:motor power:             22Kw

12: frequency Inverter:         1pc

13:slitting upper and lower circular knife         3sets

14:lower circular knife               (φ200)

15:upper circular knife               (pneumatic type)

16:sheet feed device               1set

17:hydraulic pressure station               1set

18:operation table                1set

19:outer dimension:             4130*4880*3200(mm)

20:weight:             14t

21: The dynamic balance speed is 800mpm

III:structure sketch

The machine mainly consists of frame, supporting roll, slitting part (circular knife device, bottom knife roll), slitting paper lifting device, stock form core, paper pushing device, sheet fed device, unreeling stand, main drive, brake, speed reduction, hydraulic station, control panel, motor, etc..

1:supporting roll device:

Mainly it has driving roll and paper laying roll. The diameter is 420mm,Through the speed ,the motor drive the driving roll as well as other machine part.

1.1 driving roll(φ420)       seamless tube     1pc

1.2 paper laying roll (φ420)         seamless tube   1pc

1.3 bearing pedestal                   HT200     4pcs

2:frame:

Front column, back column, beam composes the frame-type structure. It has good rigidity and high strength. It can assure safety work under high working speed. The guiding rail is installed on the frame. The slitting paper lifting device, paper roll core, and the layer board can slide along the guiding roll up and down.

2.1 front and back column       welding part   4pcs

2.2 base plate                     HT200     2pcs

2.3 beam           welding part     4pcs

2.4 guiding rail           HT200     4pcs(electrode sparking procession)

3:stock form holding device:

The stock form holding core is installed on the layer board, slide along the guiding rail with the layer board, and receive the balance through the balance weight inside the back column. The stock form is made up of hand wheel, screw, nut, inner shaft sleeve, ratchet wheel, and latch. Pull out the latch, rotate the hand wheel, can receive the stretch of the ejection core. Put down the latch, then the ejection core is locked, can locate the ejection core.

3.1 bracket     welding part     2pcs

3.2 layer board     HT200     2pcs

3.3 holding head       45#   (one set of 3,4 inch, one set of 6,12 inch)

3.4 outer shaft sleeve     HT200   2pcs

4:slitting device:

The device is made up of lower circular knife, upper circular knife, upper circular knife beam, lower circular knife beam, gear, supporting paper roll etc..
