PRODUCT NAME: Handheld Printer
MODEL#: AB-330M
HIGHLIGHTS
- Easy Paper Loading;
- Printing speed of up to 60mm/s;
- Highly efficient lithium battery, with a stand-by time of up to 48 hours;
- The card swiping board of the handheld printer can swipe all types of magnetic stripe cards;
- The handheld printer can be used with various of portable devices;
- Small size, light weight, stable and easy operation;
- Widely used in: mobile police systems,logistics systems, mobile payment systems, field operation recording systems, etc.
OTHER VALUE-ADDED FEATURES
·Serial, USB and Bluetooth interfaces.
·Multiple languages receipt option.
·Error beeper.
·Receipt head logo.
SPECIFICATION
Printing |
Direct thermal line printing |
Paper Supply Method |
Easy Paper Loading |
Characters Per Line |
Font A:48CPL,Font B:64CPL |
Character Size |
Font A:12x24,Font B:9x17 |
Resolution |
203dpi(8dots/mm) |
Print Width |
72mm |
Printing Speed |
60mm/sec (MAX) |
Cutter Type |
Manual tearing |
|
Paper Type: Thermal Paper |
Paper Roll |
Paper Diameter: 40mm(MAX) |
|
Paper Width: 80mm |
Receive Buffer Size |
4KB |
Interface |
Serial, USB, Bluetooth |
Barcodes |
1D:CODE 39,CODE93.CODE128,EAN-8,EAN-13 |
Battery |
Type: Lithium-Ion Output:DC7.4V/Capacity:1300mAh or 2100mAh |
Battery Charger |
Input AC110~240V 1.0A, Output DC9V 1A |
Operating Temperature |
0℃~50℃ |
Storage Temperature |
-10℃~60℃ |
MCBF |
Electric Life:100,000,000 pulses Wear Life: Paper feed length Approximately 50 Km Battery: 500 Cycles Rechargeable |
MSR |
Auto 1/2/3 Track(Option) |
Dimensions (W x D x H) |
100 x121 x 46 mm(No MSR) 100 x128 x 46 mm(With MSR) |
Weight |
275g |
1.Q: Are you manufactory or trade company?
A:We are professional manufactory, which specializes in POS PRINTERS, POS TERMINALS, ELECTRONIC CASH REGISTERS more than 10 years in Guangzhou ! Our advanced full set equipments make sure good quality and competitive price!
2.Q: How can I get the samples?
A: Send inquiry → Offer quotation →Confirm quotation & pay tooling charge → Provide drawing → confirm drawing → make tooling & samples → Samples finished → Delivery via freight collect
3.Q: How long can I expect to get the sample?
A:Contour drawing: 2-3 days Sample time: 7-15 business days
4.Q:How long of mass production ?
A: 15-30 business days. It depends on different order quantities and part number.
As one of the biggest manufactures of POS terminals,mini printers and electronic cash registers in China.
We have more than 300 employees and over 13000sqm factory and office building area.
At present, ZONERICH has launched its products in the markets of more than 50 countries.
