Label Printer ZQ-F920

Label Printer ZQ-F920 photo-1
US$ 1 - 1,000 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Other, Thermal
Style:
Black And White
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou China
Delivery Detail:
Delivery time depends on order quantity.
Products Status Stock
Type Other, Thermal
Style Black And White
Use Barcode Printer
Interface Type Other, USB, Parallel
Max Paper Size 110mm
Black Print Speed 250mm/s
Max. Resolution 203DPI
Brand Name ZONERICH
Model Number AB-F920
Place of Origin Guangdong, China

Specifications

1. Speed up to 250mm/s
2. LCD display
3. 1D, 2D barcode are available
4. Reliable and low cost

PRODUCT NAME: L ABEL PRINTER

MODEL#: AB-F920

Zonerich label printer is with low cost, reliable design, ideal for retail, logistics, public service, etc. Ultra speed up to 250mm/s, high resolution produces high quality labels



HIGHLIGHTS

  1. Speed up to 250mm/s
  2. LCD display
  3. 1D, 2D barcode are available
  4. Reliable and low cost



APPICATION REFERENCE

-Ideal for

-Industrial supply chain

-Goods Labeling

-Transportation and logistics

-Retail

-Public service





SPECIFICATION

Print Methods

Thermal transfer or direct thermal

Resolution

203DPI

MAX Print Speed

MAX 250mm/s

Paper Type

Width:MAX14mm, MIN 25mm

Length:12~2286mm

Thickness:0.2mm

Weight: MAX 240g/m2

MAX Diameter: Built-in roll paper max diameter 110mm, External roll paper max diameter 214mm

Winding type: According to outward printing side

Roll inner diameter:φ25.7±0.3mm

Paper gap:0.2mm

Ribbon Type

Ribbon form: Winding drum

Ribbon Width: MAX 110mm, MIN 40mm

MAX Ribbon External Diameter:φ67mm

Character Size

A : 12x24, B : 9x17

Character Set

ANK, Chinese(GB2312)

Buffer Size

4MB

Barcode types

1D bar code, Code 39, Code 93, Code 128 UCC, Code 128, Subsets A, B, and C, Coda bar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC with 2 or 5 digits add-on, MSI, PLESSEY, Postnet, China post, 2D bar code, Maxicode, PDF-417, DataMatrix, QR code, GS1 DataBar family (RSS)

Interface

USB, parallel

Power

INPUT:110-240V,50-60HZ; OUTPUT:DC24V...2A

Environmental

Operating temperature and humidity: -10-45°C; 35-85% RH

Dimension

L306mm x W228mm x H185mm
